Emission System - Exhaust Gas - Recirculation (E.G.R.) fit your 1998 Ford Explorer 6 Cyl 4.0L 5-Speed Automatic Transmission 5R55E
Currently shopping for
1998 Ford Explorer
Change VehicleVehicle Options
6 Cyl 4.0L; 5-Speed Automatic Transmission 5R55EVehicle Options
6 Cyl 4.0L; 5-Speed Automatic Transmission 5R55ECategories Close X
Currently selected
Fuel System & Manifolds
- Emission System - Exhaust Gas - Recirculation (E.G.R.)
- Evap Tube & Related Parts
- Exhaust Gas Oxygen (Hego) & Catalyst Temp. Monitor (Ctm) Sensors
- Exhaust Manifold
- Fuel Filler Pipe Installation
- Fuel Injection Manifold Injectors, Valves & Wiring
- Fuel Injection Pulse Dampener, Tubing & Wiring - Returnless Fuel System
- Fuel Lines, Tank & Related Parts
- Intake Manifold Tube Assembly - Brake
- Manifold & Related Parts - Exhaust
- Vacuum Harness
- Vacuum System - Front Axle
- Vapor Management Valve & Lines
Other Categories
Accelerator Linkage, Air Cleaner & Speed Control
Air Conditioner, Radio & Shock Absorbers
Alternator, Battery, Distributor & Starter
Automatic Transmission
Console, instruments, mirrors, windshield
Door glass and fittings
EM Exterior Moulding
Engine
Fenders & Hood
Frame, Exhaust System & Springs
Front Axle & Steering
Fuel filler, luggage carrier, rear door
IT Body & Soft Trim Parts
Lamps & Wiring
Manual Transmission
Radiator & Grill
Rear Axle, Drive & Coupling Shafts
SM Sheet metal
Seats and belts
Speedometer, Bumpers, Mirrors & Wipers
Wheels & Brakes
Parts Questions
Sort by:
Recommended
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
Part Description
- SENSOR ASY. (EGR PRESSURE VALVE)
F77Z-9J460-AB
Sensor Assy- Motorola 1.0 volt, OHV
Motorola. 1.0 volt, SOHC - Fit Note: 6 Cyl 4.0L
- Base Number: 9J460
- Callout Name: 9J460
$117.82 $71.281
-W701769-S309
Bolt- Bolt-M5 x 20.4 hex flange. Attach 9J460, SOHC
- Fit Note: 6 Cyl 4.0L
- Base Number: HB1
- Callout Name: 9J460
$10.00 $5.854- $117.82 $71.281
- VALVE (POSITIVE CRANKCASE VENTILATION)-(P.C.V.)
F77Z-6C342-AB
Hose - Connecting- Includes E97E-6A666-A2A PCV valve, SOHC
- Fit Note: 6 Cyl 4.0L
- Base Number: 6C342
- Callout Name: 6A666
$70.33 $48.951
$20.73 $13.001
- F77Z-6C342-AB
HOSE ASY. (POSITIVE CRANKCASE VENT)Hose - Connecting- Includes E97E-6A666-A2A PCV valve, SOHC
- Fit Note: 6 Cyl 4.0L
- Base Number: 6C342
- Callout Name: 6C342
$70.33 $48.951
E6AZ-9D476-B
GASKET (EXHAUST GAS RECIRCULATION VALVE)Gasket- OHV/SOHC
- Fit Note: 6 Cyl 4.0L
- Base Number: 9D476
- Callout Name: 9D476
$1.00 $0.6410
- HOSE (POSITIVE CRANKCASE VENTILATION TUBE)
$8.35 $5.711
F57Z-6853-CB
Hose - Connecting- Hose from air cleaner tube to filler neck, SOHC-Before 7/24/00
- Fit Note: 6 Cyl 4.0L
- Base Number: 6853
- Callout Name: 6A664
- CONNECTOR (EGR EXHAUST MANIFOLD)
F57Z-9F485-A
Connector- Attach to 9E469 EGR tube, SOHC
- Fit Note: 6 Cyl 4.0L
- Base Number: 9F485
- Callout Name: 9F485
$12.37 $8.681
- TUBE ASY. (FUEL VAPOR RETURN)
F77Z-9G271-AA
Hose - Connecting- Engine mounted vapor hose. Mounts to bottom of L/H & R/H side of intake. Includes Tee to VMV hose., 4.0L SOHC
- Base Number: 9G271
- Callout Name: 9G271
$258.18 $161.881
F77Z-9G271-BD
Hose - Connecting- Line from VMV valve to engine., 4.0L SOHC
- Base Number: 9G271
- Callout Name: 9G271
$45.09 $29.02- F67Z-9G271-CA
Hose - Connecting- Approx. 8.25" long; Vapor return & test port, vapor-management-valve to engine., 5.0L
- Base Number: 9G271
- Callout Name: 9G271
- F67Z-9G271-DA
Hose - Connecting- Hose from VMV valve to engine., 5.0L
- Base Number: 9G271
- Callout Name: 9G271
- F87Z-9G271-GA
Hose - Connecting- Identification tag color - yellow, approximately 36" long, comes off top port of "9F931"., 4.0L OHV
- Base Number: 9G271
- Callout Name: 9G271
- TUBE (FUEL TANK VENT TO STORAGE CANISTER)
F57Z-9A228-BC
Tube - Fuel Vapour- Outlet tube - Fuel/Vapor Storage Cannister; from cannister to engine., 4 door
- Base Number: 9A228
- Callout Name: 9A228
$140.18 $87.891
F57Z-9A228-C
Tube - Fuel Vapour- Inlet tube - Fuel/Vapor Storage Cannister; from tank to cannister.
- Base Number: 9A228
- Callout Name: 9A228
$98.00 $61.451- F57Z-9A228-AC
Tube - Fuel Vapour- Outlet tube - Fuel/Vapor Storage Cannister; from cannister to engine., 2 door
- Base Number: 9A228
- Callout Name: 9A228
- MANIFOLD (EXHAUST)
-W705495-S431
Stud- Stud-M8 x 17.9mm + M8 x 19.35 (attach 9430/9431 to cyl head), SOHC
- Fit Note: 6 Cyl 4.0L
- Require Quantity: 6
- Package Quantity: 4
- Callout Name: 9430
- Replaced By: -W705495-S900
$7.85 $4.604
-W701868-S300
Stud- (AW-93-J)-Stud (exh. manifold to cyl. head, 2 ea RH and LH) M8 x 13 + M8 x 37 Flat Drive, OHV
(AW-93-J)-Stud (exh. manifold to cyl. head, 2 ea RH and LH) M8 x 13 + M8 x 37 Flat Drive, SOHC - Fit Note: 6 Cyl 4.0L
- Require Quantity: 4
- Package Quantity: 4
- Base Number: W701868-S300
- Callout Name: 9430
$10.00 $5.854
-W702586-S301
Nut - Hex.- (AM-152-M)-Nut M8 Hex Flange High Temp (exh. manifold -mounting stud W701868-S300., OHV
(AM-152-M)-Nut M8 Hex Flange High Temp (exh. manifold -mounting stud W701868-S300., SOHC - Fit Note: 6 Cyl 4.0L
- Require Quantity: 4
- Package Quantity: 1
- Callout Name: 9430
- Replaced By: -W711402-S900
$13.00 $7.611
-W703974-S300
Spacer- Spacer; Install on the upper/rear stud on both sides prior to installation of manifold as a locator to ensure proper alignment.
- Fit Note: 6 Cyl 4.0L
- Require Quantity: 2
- Package Quantity: 1
- Base Number: HM1
- Callout Name: 9430
$8.50 $4.971- F77Z-9430-CA
Manifold Assy - Exhaust- RH, SOHC
- Location: Passenger Side
- Fit Note: 6 Cyl 4.0L
- Callout Name: 9430
- Replaced By: YU3Z-9430-AA
$370.00 $241.981 - -W701869-S100
Bolt- (AB-118-GL)-Bolt (Exh manifold to cyl head, 4 ea R.H./L.H.) - M8 x 75mm Hex Flange Head, SOHC
- Fit Note: 6 Cyl 4.0L
- Require Quantity: 8
- Package Quantity: 1
- Callout Name: 9430
- -W701869-S300
Bolt- (AB-118-GL)-Bolt (Exh manifold to cyl head, 4 ea R.H./L.H.) - M8 x 75mm Hex Flange Head, OHV
- Fit Note: 6 Cyl 4.0L
- Require Quantity: 8
- Package Quantity: 1
- Base Number: W701869-S100
- Callout Name: 9430
- F77Z-9431-CA
Manifold Assy - Exhaust- LH, SOHC
- Location: Driver Side
- Fit Note: 6 Cyl 4.0L
- Callout Name: 9430
- Replaced By: YU3Z-9431-AA
- F87Z-9430-AA
Manifold Assy - Exhaust- RH, OHV
- Location: Passenger Side
- Fit Note: 6 Cyl 4.0L
- Callout Name: 9430
- F87Z-9431-AA
Manifold Assy - Exhaust- LH, OHV
- Location: Driver Side
- Fit Note: 6 Cyl 4.0L
- Callout Name: 9430
- VALVE ASY. (EXHAUST GAS RECIRCULATION)
$144.91 $87.671 - $135.82 $82.171
$127.09 $75.351- $87.64 $53.021
$131.09 $79.311
$131.09 $82.19
-N807843-S431
Screw And Washer Assy- Require Quantity: 2
- Package Quantity: 1
- Base Number: HS1
- Callout Name: 9D475
$131.09 $82.19
$3.25 $1.914
F67Z-9J469-AA
SEAL (EGR TUBE RETAINER)Seal- Thin (Inner). Also serviced in 9E470., OHV, FROM 9/16/96
Thin (Inner). Also serviced in F77Z-9E470-AG/BA, SOHC - Fit Note: 6 Cyl 4.0L
- Base Number: 9J469
- Callout Name: 9J469
$7.05 $4.951
- TUBE ASY. (EGR VALVE INLET)
F77Z-9E469-AD
Tube - Egr Valve To Exhaust Manifld- EGR valve to exhaust manifold. See 9E470 Tube-EGR valve to upper intake manifold., SOHC
- Fit Note: 6 Cyl 4.0L
- Base Number: 9E469
- Callout Name: 9E469
$161.67 $103.311
F87Z-9E469-CA
Tube - Egr Valve To Exhaust Manifld- OHV
- Fit Note: 6 Cyl 4.0L
- Base Number: 9E469
- Callout Name: 9E469
$50.17 $36.121
E7TZ-9H465-A
VALVE ASY. (SOLENOID VACUUM)Valve Assy- Mounts to 9S430, SOHC
- Fit Note: 6 Cyl 4.0L
- Base Number: 9H465
- Callout Name: 9H465
F57Z-9J459-C
CONTROL ASY. (EGR VACUUM REGULATOR)Valve Assy- OHV
SOHC - Callout Name: 9J459
- Replaced By: F63Z-9J459-AA
$44.03 $30.911- OHV
- F57Z-9S454-AA
PAD (CONTROL ASY. EGR VACUUM REGULATOR)Pad- Attach to 9J459. Mounts 9J460. , OHV
- Fit Note: 6 Cyl 4.0L
- Callout Name: 9S454
$10.00 $5.854
- $10.00 $5.854
- HOSE (EGR VACUUM CONTROL VALVE)
F57Z-9P761-P
Hose Assy- 4.0mm ID; 205mm long, OHV, Short hose
- Fit Note: 6 Cyl 4.0L
- Callout Name: 9P761
- Replaced By: 1L3Z-9P761-AA
$154.4425
F77Z-9P761-AA
Hose Assy- 5.5 ID; 117mm long, SOHC, Long hose
- Fit Note: 6 Cyl 4.0L
- Callout Name: 9P761
- Replaced By: 1L3Z-9P761-BA
$159.1225- $8.02 $5.631
- F87Z-9P761-DA
Hose Assy- 5.6mm ID; 200mm long, OHV, Long hose
- Fit Note: 6 Cyl 4.0L
- Callout Name: 9P761
- Replaced By: 1L3Z-9P761-BA
$159.1225
F67Z-9C915-BA
VALVE ASY. (FUEL VAPOR STORAGE CANISTER PURGE)Valve Assy- VMV valve; F67E 9C915-BA, OHV & SOHC
- Fit Note: 6 Cyl 4.0L
- Base Number: 9C915
- Callout Name: 9C915
$111.09 $65.871
F6TZ-9F931-BA
BRACKET (VAPOR MANAGEMENT VALVE)Bracket- VMV mounting bracket, OHV
VMV mounting bracket, SOHC - Fit Note: 6 Cyl 4.0L
- Base Number: 9F931
- Callout Name: 9F931
$35.74 $19.151
- CONNECTION ASY. (EMISSION VACUUM MAIN)
F77Z-9E498-FB
Connector- Attach to 9C915 Vapor Management Valve, OHV/SOHC
- Fit Note: 6 Cyl 4.0L
- Base Number: 9E498
- Callout Name: 9E498
$111.17 $64.641
F87Z-9E498-RA
Connector- Main-on engine. 6 lines. 1100mm long., OHV
- Fit Note: 6 Cyl 4.0L
- Base Number: 9E498
- Callout Name: 9E498
- TUBE ASY. (EGR VALVE INLET)
F77Z-9E470-BA
Tube - Connecting- Includes (1) 9J469 rubber seal(inner), SOHC, FROM 11/1/96
- Fit Note: 6 Cyl 4.0L
- Base Number: 9E470
- Callout Name: 9E470
F87Z-9E470-AD
Tube - Connecting- Contains (1) O'ring F67Z-9J469-AA., OHV
- Fit Note: 6 Cyl 4.0L
- Base Number: 9E470
- Callout Name: 9E470
Genuine Ford Parts, the Right Choice
FordPartsGiant.com offers the wholesale prices for genuine 1998 Ford Explorer parts. Parts like Emission System - Exhaust Gas - Recirculation (E.G.R.) are shipped directly from authorized Ford dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 6 Cyl 4.0L. Transmission: 5AT 5R55E.
