Manifold And Related Parts fit your 1986 Ford F-150 6 Cyl 4.9L 4-Speed Manual Transmission
Currently shopping for
1986 Ford F-150
Change VehicleVehicle Options
6 Cyl 4.9L; 4-Speed Manual TransmissionVehicle Options
6 Cyl 4.9L; 4-Speed Manual TransmissionCategories Close X
Currently selected
Fuel System & Manifolds
- Emission System - Exhaust Gas - Recirculation (E.G.R.)
- Fuel Filler Door
- Fuel Filler Pipe Installation
- Fuel Pump - Gas Line Filter
- Fuel System & Manifolds
- Fuel System And Related Parts
- Manifold And Related Parts
- Midship Tank
- Oil Pressure Sender Installation
- Thermactor Emission Control System
- Under 8500# G.V.W. E-F250/350-Over 8500# G.V.W.
- Wiring - Fuel System And Related Parts
Other Categories
Accelerator Linkage, Air Cleaner & Speed Control
Air Conditioner, Radio & Shock Absorbers
Alternator, Battery, Distributor & Starter
BODY Body
Engine
Fenders & Hood
Frame, Exhaust System & Springs
Front Axle & Steering
Lamps & Wiring
Manual Transmission
Radiator & Grill
Rear Axle, Drive & Coupling Shafts
Speedometer, Bumpers, Mirrors & Wipers
Wheels & Brakes
Parts Questions
Sort by:
Recommended
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
Part Description
E7TZ-9B471-A
NUT AND FERRULE ASSY. (EXHAUST AIR SUPPLY)Nut - Union- Require Quantity: 6
- Package Quantity: 1
- Base Number: 9B471
- Callout Name: 9B471
$43.76 $32.031
- MANIFOLD (EXHAUST)
-390589-S8
Stud-5/16-18-18X2.625 Hex Shield- (WW-161-C) stud (alt. 9424) 5/16-18-18 x 2.65" hex shoulder , STANDARD PART
- Require Quantity: 4
- Package Quantity: 1
- Base Number: 390589-S8
- Callout Name: 9430
$18.75 $13.731
-390530-S2
Bolt-3/8-16 X 1.25 Hex Flange- (BB-416-BF)-bolt (att. manifold)-10 3/8" -16 x 1.25 hex head , STANDARD PART
- Require Quantity: 10
- Package Quantity: 2
- Base Number: 390530-S2
- Callout Name: 9430
$9.66 $5.65
- -389199-S36
Stud 5/16-18-18X2.98 Shield- (WW-161-O) stud (alt. 9424) 5/16-18-18 x 2.98" hex shoulder , STANDARD PART
- Require Quantity: 2
- Package Quantity: 1
- Base Number: 389199-S36
- Callout Name: 9430
- -390358-S8
Bolt 5/16-18X1.75 He- (BB-551-DM) bolt (alt. 9424) 5/16-18 x 1 3/4" hex flange , STANDARD PART
- Require Quantity: 4
- Package Quantity: 1
- Base Number: 390358-S8
- Callout Name: 9430
-390528-S100
Stud- (WW-122-C)-stud (att. manifold)- 3/8" - 16 x 2.42 hex shoulder , STANDARD PART
- Require Quantity: 3
- Package Quantity: 1
- Base Number: 390528-S2
- Callout Name: 9430
- -390653-S8
Bolt - Flanged Hex.- (BB-551-DY) bolt (alt. 9424) 5/16-18 x 6.07" hex flange to cyl head , STANDARD PART
- Require Quantity: 2
- Package Quantity: 1
- Callout Name: 9430
- E5TZ-9430-D
Manifold Assy - Exhaust- R.H. -does not have thermactor air holes , U/8500# GVW "From 12/84"
- Location: Passenger Side
- Callout Name: 9430
- E6AZ-9430-G
Manifold Assy - Exhaust- R.H. (retain for 1986 only) -with EGR hole. Plug D9ZZ-9G458-A
- Location: Passenger Side
- Callout Name: 9430
- MANIFOLD (INTAKE)-390530-S2
Bolt-3/8-16 X 1.25 Hex Flange- (BB-416-BF) bolt 3/8-16 x 1.25 hex flange (att. exh. manifold to cyl head) , STANDARD PART
- Require Quantity: 12
- Package Quantity: 2
- Base Number: 390530-S2
- Callout Name: 9424
$9.66 $5.65 - -374047-S
Bolt - Hex.Head - Self-Locking- (BB-869-D) screw & washer assy. (manifold to cyl. head)-hex. head-3/8" 16 x 1 5/16" , STANDARD PART
- Base Number: 374047-S
- Callout Name: 9424
- -389199-S36
Stud 5/16-18-18X2.98 Shield- (WW-161-O) stud (attach 9424) 5/16-18-18 x 2.98" hex shoulder , STANDARD PART
- Require Quantity: 4
- Package Quantity: 1
- Base Number: 389199-S36
- Callout Name: 9424
- -390249-S2
Screw 5/16 18X1 21 Pan Hd- (BB-637-LBO) screw (att. upper to lower 9424) 5/16-18 x 1 7/32 torx head , STANDARD PART
- Callout Name: 9424
- -390948-S36
Stud-5/16-18/1/4-20X- STANDARD PART , Stud 5/16-18/1/4-20x5.31 hex shoulder (att. 9424 to cyl head, att. coil/brkt
- Require Quantity: 2
- Package Quantity: 1
- Base Number: 390948-S36
- Callout Name: 9424
- D7TZ-9424-K
Manifold Assy - Inlet- .59 hole located on carb mtg pad #E5TE 9425-GA , U/8500# GVW
- Callout Name: 9424
- GASKET (CARBURETOR) - ALSO REFER TO GROUP 9A589
E5HZ-9C477-B
Gasket- CARB TO SPACER - #D9TE 9C477-BC, E5HE 9C477-BA , with 4/B carb.
- Base Number: 9C477
- Callout Name: 9447
$6.18 $3.981
- E5ZZ-9C477-A
Gasket- CARB TO MANIFOLD - Used between shield & spacer , with 4/B carb.
- Callout Name: 9447
- VALVE ASSY. (INTEGRAL EXHAUST GAS RECIRCULATION AND BACK PRESSURE CONTROL)
- SPACER (CARBURETOR TO INTAKE MANIFOLD) - Also refer to group 9447 and 9C477
- E7TZ-9443-A
CLAMP (INTAKE and EXHAUST MANIFOLD TO CYLINDER BLOCK)Clamp Intake & Exhaust- Require Quantity: 13
- Package Quantity: 1
- Callout Name: 9443
Genuine Ford Parts, the Right Choice
FordPartsGiant.com offers the wholesale prices for genuine 1986 Ford F-150 parts. Parts like Manifold And Related Parts are shipped directly from authorized Ford dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 6 Cyl 4.9L. Transmission: 4MT.
