How to remove and install fuel injectors in diesel engine on Ford Bronco II?

Disconnect both battery ground cables for the 2.2L engine. Disconnect and remove the injection lines from the nozzles and injection pump, capping all lines and fittings. Remove the fuel return line and gaskets, and the bolts attaching the fuel line heater clamp to the cylinder head, positioning the heater out of the way. Remove the nozzles using a 27mm deepwell socket, and the nozzle washer (copper) and nozzle gasket (steel) using Tool T71P-19703-C or equivalent. Clean the nozzle assemblies with Nozzle Cleaning Kit, Rotunda 14-0301 or equivalent, and a suitable solvent, drying thoroughly. Clean the nozzle seats in the cylinder head with Nozzle Seat Cleaner, T83T-9527-B or equivalent. Position the new nozzle washers and gaskets in the nozzle seats, install the nozzles and tighten. Install the nozzle gaskets with blue side face up (toward nozzle). Position the fuel line heater clamps and install attaching bolts. Install the fuel return line with new gaskets on nozzles. Install the injection lines on the nozzles and injection pump and tighten the line nuts. Connect both battery ground cables. Run the engine and check for fuel leaks.For the 2.3L engine, disconnect battery ground cables from both batteries. Disconnect and remove injection lines from injection nozzles and injection pump, capping all lines and fittings using Protective Cap Set, T85T- 9395-A, or equivalent. Remove fuel return pipe and gaskets. Remove nozzles using a 21mm deep well socket. Remove holder gasket and nozzles gasket using 0-ring Tool T71P-19703-C or equivalent. Clean exterior of nozzle assemblies using brass brush from Nozzle Clean Kit 014-00301, or equivalent and a suitable solvent, drying thoroughly. Install new nozzle gasket and holder gasket in cylinder. Install nozzles and tighten to specification, using a 21mm deep well socket. Install fuel return pipe using new gaskets. Tighten nuts to specification. Install injection lines on nozzle and fuel injection pump and tighten line nuts to specification. Connect battery ground cables to both batteries. Run engine and check for fuel leaks.

Genuine Ford Fuel Injector

Gas Injector

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

220 Fuel Injectors found

View related parts
Ford Injector
Part Number: BR3Z-9F593-B
$46.47 MSRP: $75.27
You Save: $28.80 (39%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- Edge | 2011-2019 | 6 Cyl 3.5L Cyclone Petrol TIVCT, 6 Cyl 3.5L DOHC VCT SMPI, 6 Cyl 3.7L DOHC | 6-Speed Automatic Transmission 6DCT450 - MPS6, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F50, 6-Speed Automatic Transmission 6F55, 6-Speed Manual Transaxle - MMT6, 8-Speed Automatic Transmission 8F57, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Front-Wheel Drive (Right Hand Drive), Left Hand Drive, RHD 4WD (FTD)
- Explorer | 2011-2019 | 6 Cyl 3.5L Cyclone Petrol TIVCT, 6 Cyl 3.7L DOHC | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F50, 6-Speed Automatic Transmission 6F55, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- F-150 | 2011-2017 | 6 Cyl 3.5L Cyclone Petrol TIVCT, 6 Cyl 3.7L PFI NA | 10-Speed Automatic Transmission (10R80), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Manual Transmission - Mazda M5R2-C, 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- Flex | 2013-2019 | 6 Cyl 3.5L Cyclone Petrol TIVCT | 6-Speed Automatic Transmission 6F50, 6-Speed Automatic Transmission 6F55, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Mustang | 2011-2019 | 6 Cyl 3.7L PFI NA | 10-Speed Automatic Transmission (10R80), 6-Speed Automatic Transmission (6R80), 6-Speed Manual Transmission (T56), 6-Speed Manual Transmission-3160, 6-Speed Manual Transmission-MT82, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- Police Interceptor Sedan | 2019 | 6 Cyl 3.5 L FLEX, 6 Cyl 3.5 L GAS, 6 Cyl 3.7 L FLEX
- Police Interceptor Utility | 2019 | 6 Cyl 3.5 L GAS, 6 Cyl 3.7 L FLEX
- Taurus | 2013-2019 | 6 Cyl 3.5L Cyclone Petrol TIVCT, 6 Cyl 3.7L DOHC | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F50, 6-Speed Automatic Transmission 6F55, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Transit | 2015-2019 | 6 Cyl 3.7L PFI NA | 6-Speed Automatic Transmission (6R80)
View More
View related parts
Ford Injector
Part Number: BL3Z-9F593-B
$113.36 MSRP: $183.64
You Save: $70.28 (39%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
- Replaces: CM-5202, BL3Z-9F593-A
Fits the following Ford Models:
- Expedition | 2015-2017 | 6 Cyl 3.5L GTDI | 4AT 4R75W, 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 6-Speed Automatic Transmission (6R75), 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-150 | 2011-2016 | 6 Cyl 3.5L DOHC TIVCT, 6 Cyl 3.5L GTDI | 10-Speed Automatic Transmission (10R80), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Manual Transmission - Mazda M5R2-C, 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- Transit | 2015-2024 | 6 Cyl 3.5 L GAS, 6 Cyl 3.5L GTDI | 6-Speed Automatic Transmission (6R80)
View More
View related parts
Ford Injector
Part Number: BR3Z-9F593-A
$62.85 MSRP: $101.82
You Save: $38.97 (39%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- F-150 | 2011-2017 | 8 Cyl 5.0L MOD DOHC SEFI NA | 10-Speed Automatic Transmission (10R80), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Manual Transmission - Mazda M5R2-C, 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- Mustang | 2011-2020 | 4 Cyl 2.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.0L DOHC EFI Modular, 8 Cyl 5.0L MOD DOHC SEFI NA, 8 Cyl 5.2 L GAS, 8 Cyl 5.2L | 10-Speed Automatic Transmission (10R80), 6-Speed Automatic Transmission (6R80), 6-Speed Manual Transmission (T56), 6-Speed Manual Transmission-3160, 6-Speed Manual Transmission-MT82, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Injector
Part Number: EJ7Z-9F593-C
$69.70 MSRP: $112.91
You Save: $43.21 (39%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
- Replaces: CM-5251, EJ7Z-9F593-B, EJ7Z-9F593-A, CM-5232
Fits the following Ford Models:
- Explorer | 2016-2019 | 4 Cyl 2.3L TIVCT DI TC | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F50, 6-Speed Automatic Transmission 6F55, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Focus | 2016-2018 | 4 Cyl 2.3L Ecoboost | 1-Speed Transmission, 5-Speed Manual Transmission - B5/IB5, 5-Speed Manual Transmission - MTX75, 6-Speed Automatic Transmission 6DCT450 - MPS6, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F15, 6-Speed Automatic Transmission DPS6, 6-Speed Manual Transaxle - MMT6, 6-Speed Manual Transmission - B6, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Front-Wheel Drive (Right Hand Drive), Left Hand Drive, RHD 4WD (FTD)
- Mustang | 2015-2023 | 4 Cyl 2.3 L GAS, 4 Cyl 2.3L TIVCT DI TC, 8 Cyl 5.0 L GAS, 8 Cyl 5.2 L GAS | 10-Speed Automatic Transmission (10R80), 6-Speed Automatic Transmission (6R80), 6-Speed Manual Transmission-3160, 6-Speed Manual Transmission-MT82, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View More
View related parts
Ford Fuel Remanufactured Injector Assembly
Part Number: 4C3Z-9E527-BRM
$282.02 MSRP: $312.86
You Save: $30.84 (10%)
ADD TO CART
Product Specifications
- Other Name: Nozzle Assembly; Injector assembly
- Replaced by: 4C3Z-9E527-ARM
Fits the following Ford Models:
- E-150 | 2005-2010 | 8 Cyl 6.0L Diesel OHV DI | 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO
- E-250 | 2005-2010 | 8 Cyl 6.0L Diesel OHV DI | 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO
- E-350/E-350 Super Duty | 2005-2010 | 8 Cyl 6.0L Diesel OHV DI | 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO
- E-450 Super Duty | 2005-2010 | 8 Cyl 6.0L Diesel OHV DI | 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO
- F-250 Super Duty | 2005-2007 | 8 Cyl 6.0L Diesel OHV | 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-350 Super Duty | 2005-2007 | 8 Cyl 6.0L Diesel OHV | 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-450 Super Duty | 2004-2007 | 8 Cyl 6.0L Diesel OHV, 8 Cyl 6.0L Diesel Turbocharged | 4AT 4R100, 5AT, 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6MT, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-550 Super Duty | 2005-2007 | 8 Cyl 6.0L Diesel OHV | 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View More
View related parts
Ford Injector
Part Number: 5C3Z-9F593-DC
$53.53 MSRP: $86.73
You Save: $33.20 (39%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- Expedition | 2005-2006 | 8 Cyl 5.4L | 4AT 4R75W, 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 6-Speed Automatic Transmission (6R75), 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-150 | 2005-2007 | 8 Cyl 5.4L | 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Manual Transmission - Mazda M5R2-C, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-250 Super Duty | 2005-2007 | 8 Cyl 5.4L | 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-350 Super Duty | 2005-2007 | 8 Cyl 5.4L | 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-450 Super Duty | 2005-2007 | 8 Cyl 5.4L | 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-550 Super Duty | 2005-2007 | 8 Cyl 5.4L | 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View More
View related parts
Ford Injector
Part Number: 5L2Z-9F593-CB
$69.37 MSRP: $112.36
You Save: $42.99 (39%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
- Manufacturer Note: Injector O-Rings Are Not Serviced Separately. Available Only With Injector Asy.
- Replaces: 5L2Z-9F593-CA
Fits the following Ford Models:
- Explorer | 2006-2010 | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission 5R55S, 5-Speed Automatic Transmission 5R55W, 5-Speed Manual Transmission (M5R4), 6-Speed Automatic Transmission (6R80), 6-Speed Automatic Transmission 6R60, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Right Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- Explorer Sport Trac | 2007-2010 | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission 5R55S, 6-Speed Automatic Transmission (6R80), 6-Speed Automatic Transmission 6R60, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- Mustang | 2005-2010 | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission 5R55S, 5-Speed Manual Transmission T5OD, 5-Speed Manual Transmission TR3650, 6-Speed Manual Transmission (T56), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- Ranger | 2005-2011 | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission - 5R44E/5R55E, 5-Speed Manual Transmission - R1HD, 5-Speed Manual Transmission M5R1, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View More
View related parts
Ford Injector
Part Number: 8S4Z-9F593-A
$63.53 MSRP: $102.91
You Save: $39.38 (39%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- C-Max | 2013-2018 | 4 Cyl 2.0L Duratec Hybrid (130kW) | ECVT Auto Trans Power Split, Front-Wheel Drive (Left Hand Drive), Left Hand Drive, Two-Wheel Drive (Left Hand Drive)
- Focus | 2008-2011 | 4 Cyl 2.0L Duratec HE | 4-Speed Automatic Transaxle - 4F27E, 5-Speed Manual Transmission - MTX75, Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Fusion | 2013-2020 | 4 Cyl 1.5 L GAS, 4 Cyl 2.0 L FULL HYBRID EV-GAS (FHEV), 4 Cyl 2.0 L GAS, 4 Cyl 2.0L Duratec Hybrid (130kW), 4 Cyl 2.5 L FLEX, 4 Cyl 2.5 L GAS | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F55, 6-Speed Manual Transmission - B6, ECVT Auto Trans Power Split, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Transit Connect | 2010-2013 | 4 Cyl 2.0L Duratec HE | 1-Speed Transmission, 4-Speed Automatic Transaxle - 4F27E, Front-Wheel Drive (Left Hand Drive), Front-Wheel Drive (Right Hand Drive), Left Hand Drive
View More
View related parts
Ford Injector
Part Number: 9L8Z-9F593-A
$72.11 MSRP: $100.36
You Save: $28.25 (29%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- Escape | 2009-2012 | 6 Cyl 3.0L OHC Duratec | 4AT CD4E, 5-Speed Manual Transmission - AK, 6-Speed Automatic Transmission 6F Mid-Range, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Fusion | 2010-2012 | 6 Cyl 3.0L OHC Duratec | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Injector
Part Number: 9E5Z-9F593-A
$53.77 MSRP: $87.09
You Save: $33.32 (39%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- Escape | 2009-2025 | 3 Cyl 1.5 L GAS, 4 Cyl 2.0 L GAS, 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV), 4 Cyl 2.5 L PLUG-IN HYBRID EV-GAS (PHEV), 4 Cyl 2.5L Duratec (110kW/150PS), 4 Cyl 2.5L Duratec FFV (125kW/170PS), 4 Cyl 2.5L PFI Gas/Electric | 4AT CD4E, 5-Speed Manual Transmission - AK, 6-Speed Automatic Transmission 6F Mid-Range, CVT Auto Trans Powersplit Elec, Four-Wheel Drive, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Front-Wheel Drive (Right Hand Drive), Left Hand Drive, Two-Wheel Drive (Left Hand Drive)
- Fusion | 2018-2020, 2010-2012 | 4 Cyl 1.5 L GAS, 4 Cyl 2.0 L FULL HYBRID EV-GAS (FHEV), 4 Cyl 2.0 L GAS, 4 Cyl 2.5 L FLEX, 4 Cyl 2.5 L GAS, 4 Cyl 2.5L Duratec (110kW/150PS), 4 Cyl 2.5L Duratec FFV (125kW/170PS), 4 Cyl 2.5L Duratec HE PFI, 4 Cyl 2.5L PFI Gas/Electric | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F55, 6-Speed Manual Transmission - B6, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, ECVT Auto Trans Power Split, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Maverick | 2022-2024 | 4 Cyl 2.0 L GAS, 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV)
- Transit Connect | 2014-2022 | 4 Cyl 2.0 L FLEX, 4 Cyl 2.0 L GAS, 4 Cyl 2.5 L CNG, 4 Cyl 2.5 L GAS, 4 Cyl 2.5 L LPG, 4 Cyl 2.5L Duratec (110kW/150PS) | 6-Speed Automatic Transmission 6F Mid-Range, 8-Speed Automatic Transmission 8F35, Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View More
View related parts
Ford Injector
Part Number: 9L3Z-9F593-B
$55.56 MSRP: $90.00
You Save: $34.44 (39%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- Expedition | 2009-2014 | 8 Cyl 5.4L | 4AT 4R75W, 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 6-Speed Automatic Transmission (6R75), 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-150 | 2009-2010 | 8 Cyl 5.4L | 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Manual Transmission - Mazda M5R2-C, 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Injector
Part Number: 7T4Z-9F593-B
$67.69 MSRP: $109.64
You Save: $41.95 (39%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
- Replaces: 7T4Z-9F593-A
Fits the following Ford Models:
- Edge | 2007-2010 | 6 Cyl 3.5L DOHC VCT SMPI | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F50, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Flex | 2009-2012 | 6 Cyl 3.5L DOHC VCT SMPI | 6-Speed Automatic Transmission 6F50, 6-Speed Automatic Transmission 6F55, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Fusion | 2007-2012 | 6 Cyl 3.5L DOHC VCT SMPI | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Taurus | 2008-2012 | 6 Cyl 3.5L DOHC VCT SMPI | 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F50, 6-Speed Automatic Transmission 6F55, CVT Select Shift Transmission, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Taurus X | 2008-2009 | 6 Cyl 3.5L DOHC VCT SMPI | 6-Speed Automatic Transmission 6F50, Four-Wheel Drive (Part Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View More
View related parts
Ford Injector
Part Number: AL3Z-9F593-B
$75.98 MSRP: $123.09
You Save: $47.11 (39%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- F-150 | 2011-2014 | 8 Cyl 6.2L OHC NA | 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Manual Transmission - Mazda M5R2-C, 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-250 Super Duty | 2011-2015 | 8 Cyl 6.2L OHC NA | 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Automatic Transmission (6R140), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-350 Super Duty | 2011-2015 | 8 Cyl 6.2L OHC NA | 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Automatic Transmission (6R140), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-450 Super Duty | 2011-2015 | 8 Cyl 6.2L OHC NA | 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Automatic Transmission (6R140), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-550 Super Duty | 2011-2015 | 8 Cyl 6.2L OHC NA | 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Automatic Transmission (6R140), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View More
View related parts
Ford Fuel Injector
Part Number: 5C3Z-9VE527-BRM
$295.44 MSRP: $374.29
You Save: $78.85 (22%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Kit - Remanufactured Fuel Injector; Fuel Injector, Injection Nozzle
- Replaced by: TU7Z-9VE527-BRM
- Replaces: F81Z-9E527-CRM
Fits the following Ford Models:
- E-350/E-350 Super Duty | 1999-2003 | 8 Cyl 7.3L Diesel Turbocharged | 4AT 4R100, 4AT 4R70W
- Econoline Super Duty(1996-1999) | 1999 | 8 Cyl 7.3L Diesel Turbocharged | 4AT 4R100, 4AT 4R70W
- Excursion | 2000-2003 | 8 Cyl 7.3L | 4AT 4R100, 5AT
- F-250 Super Duty | 1999-2003 | 8 Cyl 7.3L | 4AT 4R100, 5AT, 5MT, 6MT
- F-350 Super Duty | 1999-2003 | 8 Cyl 7.3L | 4AT 4R100, 5AT, 5MT, 6MT
- F-450 Super Duty | 1999-2003 | 8 Cyl 7.3L Diesel Turbocharged | 4AT 4R100, 5AT, 5MT, 6MT
- F-550 Super Duty | 1999-2003 | 8 Cyl 7.3L Diesel Turbocharged | 4AT 4R100, 5AT, 5MT, 6MT
View More
View related parts
Ford Injector
Part Number: 7C3Z-9F593-A
$59.04 MSRP: $95.64
You Save: $36.60 (39%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- F-150 | 2007-2008 | 8 Cyl 5.4L | 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Manual Transmission - Mazda M5R2-C, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-250 Super Duty | 2007-2010 | 8 Cyl 5.4L | 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-350 Super Duty | 2007-2010 | 8 Cyl 5.4L | 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-450 Super Duty | 2007-2010 | 8 Cyl 5.4L | 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-550 Super Duty | 2007-2010 | 8 Cyl 5.4L | 5-Speed Automatic Transmission 5R110W - HI/Torque, 5-Speed Automatic Transmission 5R110W NAAO, 5-Speed Manual Transmission-Tremec TR4050, 6-Speed Manual Transmission M6HD-W, 6-Speed Manual Transmission Z/F S6-650, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View More
View related parts
Ford Injector
Part Number: BB5Z-9F593-B
$125.71 MSRP: $203.64
You Save: $77.93 (39%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
- Replaces: CM-5198, BB5Z-9F593-A
Fits the following Ford Models:
- Edge | 2012-2014 | 4 Cyl 2.0L EcoBoost (240PS) | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F50, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Escape | 2013-2016 | 4 Cyl 2.0L | 6-Speed Automatic Transmission 6F Mid-Range, Four-Wheel Drive, Four-Wheel Drive (Part Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Front-Wheel Drive (Right Hand Drive), Left Hand Drive, Two-Wheel Drive (Left Hand Drive)
- Explorer | 2012-2015 | 4 Cyl 2.0L EcoBoost (240PS) | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F50, 6-Speed Automatic Transmission 6F55, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Focus | 2013-2018 | 4 Cyl 2.0L EcoBoost (240PS) | 1-Speed Transmission, 5-Speed Manual Transmission - MTX75, 6-Speed Automatic Transmission 6F15, 6-Speed Automatic Transmission DPS6, 6-Speed Manual Transaxle - MMT6, 6-Speed Manual Transmission - B6, Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Fusion | 2013-2016 | 4 Cyl 2.0L EcoBoost (240PS) | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F55, 6-Speed Manual Transmission - B6, ECVT Auto Trans Power Split, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
- Taurus | 2013-2019 | 4 Cyl 2.0L EcoBoost (240PS) | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F50, 6-Speed Automatic Transmission 6F55, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View More
View related parts
Ford Injector
Part Number: 6W7Z-9F593-AA
$58.82 MSRP: $95.27
You Save: $36.45 (39%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- Crown Victoria | 2006-2011 | 8 Cyl 4.6L, 8 Cyl 4.6L Romeo SOHC EFI | 4AT, 4AT 4R75W, 4-Speed Automatic Transmission 4R75E Livonia, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Injector
Part Number: CK4Z-9E527-A
$461.31 MSRP: $587.14
You Save: $125.83 (22%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Nozzle And Holder - Fuel Injector; Injector
Fits the following Ford Models:
- Transit | 2015-2019 | 5 Cyl 3.2L Duratorq-TDCi - Puma | 6-Speed Automatic Transmission (6R80)
View related parts
Ford Injector
Part Number: XR3Z-9F593-CB
$60.62 MSRP: $98.20
You Save: $37.58 (39%)
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- Mustang | 2003-2004, 2001 | 8 Cyl 4.6L DOHC EFI | 4-Speed Automatic Transmission 4R70W (AODE), 4AT 4R75W, 5-Speed Manual Transmission (T450D), 5-Speed Manual Transmission T5OD, 5-Speed Manual Transmission TR3650, 6-Speed Manual Transmission Tremec T56, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Injector
Part Number: 9L3Z-9F593-E
$49.75 MSRP: $80.60
You Save: $30.85 (39%)
ADD TO CART
Product Specifications
- Other Name: Injector Assembly; Injector
Fits the following Ford Models:
- Explorer Sport Trac | 2009-2010 | 8 Cyl 4.6L | 5-Speed Automatic Transmission 5R55S, 6-Speed Automatic Transmission (6R80), 6-Speed Automatic Transmission 6R60, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- F-150 | 2009-2014 | 8 Cyl 4.6L | 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R70E W/TSS, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 5-Speed Manual Transmission - Mazda M5R2-C, 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
- Mustang | 2009-2010 | 8 Cyl 4.6L SOHC EFI, 8 Cyl 5.8L DOHC SC | 5-Speed Automatic Transmission 5R55S, 5-Speed Manual Transmission T5OD, 5-Speed Manual Transmission TR3650, 6-Speed Manual Transmission (T56), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View More

| Page 1 of 11 |Next >

1-20 of 220 Results

Ford Fuel Injector Parts Questions & Experts Answers

Injector Assembly
E5TZ-9F593-A
Q:
How to remove and install fuel injectors in diesel engine on Ford Bronco II?
Posted by Deon H.
A:
Disconnect both battery ground cables for the 2.2L engine. Disconnect and remove the injection lines from the nozzles and injection pump, capping all lines and fittings. Remove the fuel return line and gaskets, and the bolts attaching the fuel line heater clamp to the cylinder head, positioning the heater out of the way. Remove the nozzles using a 27mm deepwell socket, and the nozzle washer (copper) and nozzle gasket (steel) using Tool T71P-19703-C or equivalent. Clean the nozzle assemblies with Nozzle Cleaning Kit, Rotunda 14-0301 or equivalent, and a suitable solvent, drying thoroughly. Clean the nozzle seats in the cylinder head with Nozzle Seat Cleaner, T83T-9527-B or equivalent. Position the new nozzle washers and gaskets in the nozzle seats, install the nozzles and tighten. Install the nozzle gaskets with blue side face up (toward nozzle). Position the fuel line heater clamps and install attaching bolts. Install the fuel return line with new gaskets on nozzles. Install the injection lines on the nozzles and injection pump and tighten the line nuts. Connect both battery ground cables. Run the engine and check for fuel leaks.For the 2.3L engine, disconnect battery ground cables from both batteries. Disconnect and remove injection lines from injection nozzles and injection pump, capping all lines and fittings using Protective Cap Set, T85T- 9395-A, or equivalent. Remove fuel return pipe and gaskets. Remove nozzles using a 21mm deep well socket. Remove holder gasket and nozzles gasket using 0-ring Tool T71P-19703-C or equivalent. Clean exterior of nozzle assemblies using brass brush from Nozzle Clean Kit 014-00301, or equivalent and a suitable solvent, drying thoroughly. Install new nozzle gasket and holder gasket in cylinder. Install nozzles and tighten to specification, using a 21mm deep well socket. Install fuel return pipe using new gaskets. Tighten nuts to specification. Install injection lines on nozzle and fuel injection pump and tighten line nuts to specification. Connect battery ground cables to both batteries. Run engine and check for fuel leaks.
Answered by Ford Parts Specialist Bastien / Jul 02, 2023
