- WIRE ASY. (FUEL CHARGE)
$108.36 $66.891
$13.731
- PUMP ASY. (BRAKE VACUUM)
- GASKET (CYLINDER HEAD COVER)
F81Z-6584-AA
Gasket - Valve Rocker Arm Cover- Fit Note: 8 Cyl 7.3L
- Require Quantity: 2
- Package Quantity: 1
- Base Number: 6584
- Callout Name: 6584
$123.69 $102.991
1C3Z-14A163-AA
Retainer- Clip to retain wiring harness to valve cover gasket
- Fit Note: 8 Cyl 7.3L
- Require Quantity: 2
- Package Quantity: 1
- Callout Name: 6584
$13.731
- RESERVOIR (WINDSHIELD OR REAR WASHER)
$5.42 $3.802
F81Z-17618-AA
Reservoir - Windshield Washer- Reservoir & motor asy
- Callout Name: 17618
- Replaced By: 7C3Z-17618-AA
$117.45 $69.641
XC3Z-19805-CA
MOTOR ASY. (AIR CONDITIONER BLOWER)Motor - Cooling Blower- Motor, retainer, & seal
- Base Number: 19805
- Callout Name: 19805
$123.27 $76.481
- RESISTOR ASY.
- RELAY ASY. (ACCESSORY)
E9TZ-11450-B
Relay Assy - Starter Motor- Starter motor relay, includes 381561-S39 nut
- Base Number: 11450
- Callout Name: 14N089
$38.55 $23.791
F5TZ-14N089-B
Relay module- 1/2 ISO (Type 25)
1/2 ISO relay on 13B218, with production DRL
Fuel pump, park lamp, back-up lamp, 1/2 ISO (Type 25)
Lock, Unlock relay, 1/2 ISO (Type 25) - Base Number: 13A025D
- Callout Name: 14N089
- Replaced By: 5M5Z-14N089-BA
$15.47 $10.381
FOAZ-14N089-A
Relay module- ISO relay (Type 12)
ISO relay (Type 12), Injector Drive Module
ISO relay (Type 12), Transfer case relay
ISO relay on 13B218, with production DRL
TT (Type 12), ISO relay 3-in tandem - Base Number: 13A025
- Callout Name: 14N089
- Replaced By: 5M5Z-14N089-A
$28.36 $17.391
1C3Z-2C286-BB
CONTROL ASY. (ANTI-LOCK HYDRAULIC)Control Assy - Abs Hydraulics- HCU, FROM 07/16/01
- Callout Name: 2C286
- Replaced By: 5C7Z-2C286-A
- LAMP (ASY. - FOG OR ROAD) AND 13200
3C3Z-15200-BA
Lamp Assy - Fog - Front- LH includes bracket, lamp, and bulb, With production fog lamps
- Location: Driver Side
- Base Number: 15200
- Callout Name: 15200
$61.31 $44.871
3C3Z-15200-AA
Lamp Assy - Fog - Front- RH includes bracket, lamp, and bulb, With production fog lamps
- Location: Passenger Side
- Base Number: 15200
- Callout Name: 15200
- 1C3Z-15200-BB
Lamp Assy - Fog - Front- Kit to add fog lamps, same style as production fog lamps
- Base Number: 15200
- Callout Name: 15200
- HEADLAMP ASY.
2C3Z-13008-AB
Headlamp Assy- L.H., Complete Assembly, refer to 13007 for non-aero headlamps, With aero headlamps
- Location: Driver Side
- Base Number: 13008
- Callout Name: 13008
2C3Z-13008-AA
Headlamp Assy- R.H., Complete Assembly, refer to 13007 for non-aero headlamps, With aero headlamps
- Location: Passenger Side
- Base Number: 13008
- Callout Name: 13008
- 2C3Z-13008-AACP
Headlamp Assy- R.H., Truckload program, containing Qty of 4, With aero headlamps
- Location: Passenger Side
- Callout Name: 13008
F6UZ-19A706-AA
RESISTOR ASY. (BLOWER MOTOR)Resistor Assy- Callout Name: 19A706
- Replaced By: 4C2Z-19A706-AA
$42.55 $26.271
XC3Z-13832-AA
HORN ASY. (HIGH & LOW PITCH)Horn And Bracket Assy- Includes Bracket
- Base Number: 13832
- Callout Name: 13832
- Replaced By: 2W7Z-13800-AA
$52.50 $36.541
- CABLE ASY. (BATTERY) AND 14301
- LAMP ASY. (PARKING)
2C3Z-13201-AA
Parking Light - Without Bulb- L.H., Turn/park lamp with clear lenses, Except Mexican markets
- Location: Driver Side
- Base Number: 13201
- Callout Name: 13200
$31.87 $23.331
2C3Z-13200-AA
Parking Light - Without Bulb- R.H., Turn/park lamp with clear lenses, Except Mexican markets
- Location: Passenger Side
- Base Number: 13200
- Callout Name: 13200
- 2C3Z-13200-AACP
Parking Light - Without Bulb- R.H., Turn/park lamp with clear lenses, Except Mexican markets
- Location: Passenger Side
- Callout Name: 13200
2C3Z-13200-BA
Parking Light - Without Bulb- R.H., Mexican markets only
- Location: Passenger Side
- Base Number: 13200
- Callout Name: 13200
- 2C3Z-13201-AACP
Parking Light - Without Bulb- L.H., Turn/park lamp with clear lenses, Except Mexican markets
- Location: Driver Side
- Callout Name: 13200
- 2C3Z-13201-BA
Parking Light - Without Bulb- L.H., Mexican markets only
- Location: Driver Side
- Base Number: 13201
- Callout Name: 13200
- SENSOR ASY. (INTAKE AIR TEMPERATURE)
F6SZ-12A697-A
Sensor Assy- Mounted on charge air cooler manifold
- Fit Note: 8 Cyl 7.3L
- Callout Name: 12A697
- Replaced By: 9C1Z-12A697-B
$48.55 $29.961
F5AZ-12A697-A
Sensor Assy- Mounted on air cleaner, Plastic sensor
- Fit Note: 8 Cyl 7.3L
- Base Number: 12A697
- Callout Name: 12A697
$113.27 $69.931
- SCREW (HEADLAMP ADJUSTING)
F81Z-13032-BA
Screw- Vert. adj., upper screw, w/o aero headlamp
- Require Quantity: 2
- Package Quantity: 1
- Base Number: 13032
- Callout Name: 13032
F81Z-13032-AA
Screw- Horz. adj., inboard screw, w/aero lamp refer to 13008, w/o aero headlamp
- Require Quantity: 2
- Package Quantity: 1
- Callout Name: 13032
F8UZ-9F479-BA
SENSOR (MANIFOLD ABSOLUTE PRESSURE)Sensor Assy- #98AB-9F479-BA (Sensor). Attaching bracket is 9G425., Diesel, 7.3L
- Base Number: 9F479
- Callout Name: 9F479
$125.82 $77.671
- WIRING ASY. (REAR LAMP)
2C3Z-14405-AA
Wiring Assy - Rear Lamps- 137" WB, except Calif, w/o rear park aid
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-CA
Wiring Assy - Rear Lamps- 141.8" WB, except Calif, w/o rear park aid
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-AAA
Wiring Assy - Rear Lamps- 158" WB, except Calif, w/rear park aid
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-ACA
Wiring Assy - Rear Lamps- 172.4" WB, except Calif, w/rear park aid, w/o lighted running boards
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-ADA
Wiring Assy - Rear Lamps- 172.4" WB, only Calif, w/rear park aid, w/o lighted running boards
- Callout Name: 14405
- 2C3Z-14405-AEA
Wiring Assy - Rear Lamps- 172.4" WB, except Calif, w/rear park aid, w/lighted running boards
- Callout Name: 14405
- 2C3Z-14405-AFA
Wiring Assy - Rear Lamps- 172.4" WB, only Calif, w/rear park aid, w/lighted running boards
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-AGA
Wiring Assy - Rear Lamps- 140.8" WB, except Calif, w/o dual fuel tank
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-AKA
Wiring Assy - Rear Lamps- 161.8" WB, except Calif, w/o dual fuel tank
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-ANA
Wiring Assy - Rear Lamps- 164.8" WB, except Calif, w/o dual fuel tank
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-ARA
Wiring Assy - Rear Lamps- 164.8" WB, w/dual fuel tank
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-ASA
Wiring Assy - Rear Lamps- 176.2" WB, except Calif, w/o dual fuel tank
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-AUA
Wiring Assy - Rear Lamps- 176.2" WB, w/dual fuel tank
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-AVA
Wiring Assy - Rear Lamps- 188.8" WB, except Calif, w/o dual fuel tank
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-AZA
Wiring Assy - Rear Lamps- 200.2 & 200.8" WB, except Calif, w/o dual fuel tank
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-BEA
Wiring Assy - Rear Lamps- 164.8" Mexico, diesel, w/o airbag
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-BJA
Wiring Assy - Rear Lamps- W/aft of axle LPG tank(s). Inside frame rails , Mexico, LPG, 6.8L
- Callout Name: 14405
- 2C3Z-14405-EA
Wiring Assy - Rear Lamps- 156.2" WB, except Calif, w/o rear park aid, w/o lighted running boards
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-FA
Wiring Assy - Rear Lamps- 156.2" WB, only Calif, w/o rear park aid, w/o lighted running boards
- Callout Name: 14405
- 2C3Z-14405-GA
Wiring Assy - Rear Lamps- 156.2" WB, except Calif, w/o rear park aid, w/lighted running boards
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-HA
Wiring Assy - Rear Lamps- 156.2" WB, only Calif, w/o rear park aid, w/lighted running boards
- Callout Name: 14405
- 2C3Z-14405-JA
Wiring Assy - Rear Lamps- 158" WB, except Calif, w/o rear park aid
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-LA
Wiring Assy - Rear Lamps- 172.4" WB, except Calif, w/o rear park aid, w/o lighted running boards
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-NA
Wiring Assy - Rear Lamps- 172.4" WB, except Calif, w/o rear park aid, w/lighted running boards
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-PA
Wiring Assy - Rear Lamps- 172.4" WB, only Calif, w/o rear park aid, w/lighted running boards
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-VA
Wiring Assy - Rear Lamps- 156.2" WB, except Calif, w/rear park aid, w/o lighted running boards
- Base Number: 14405
- Callout Name: 14405
- 2C3Z-14405-XA
Wiring Assy - Rear Lamps- 156.2" WB, only Calif, w/rear park aid, w/o lighted running boards
- Callout Name: 14405
- 2C3Z-14405-YA
Wiring Assy - Rear Lamps- 156.2" WB, except Calif, w/rear park aid, w/lighted running boards
- Callout Name: 14405
- 3C3Z-14405-BMA
Wiring Assy - Rear Lamps- With "side saddle" LPG fuel tank(s). Located outside frame rail. , Mexico, LPG, w/415 (6.8L) V10
- Callout Name: 14405
- RETAINER (WIRE HARNESS)$13.731
E9DZ-14A163-AA
Retainer- Retainer - push pin type - 20mm serrated pin with 60mm x 10mm wing - general use for wiring to sheet metal or blind hole retention. Use electrical tape to secure to harness. 10 per package., Service Repair Only
- Base Number: 14A163B
- Callout Name: 14A163
$1.50 $1.0510
F5TZ-14A163-D
Bracket- 120 way bracket asy, #14401 to #12A581...between 14405 and 14401 in illustration P-35225.
- Callout Name: 14A163
- Replaced By: F5OY-14536-F
$30.83 $21.091- F81Z-14A163-AC
Bracket - Wiring Connector- Bracket, engine, for wire harness
- Base Number: 14A163A
- Callout Name: 14A163
$18.75 $13.731 - 2C3Z-14A163-BA
Clip - Wiring- Bracket with snap clip at steering column
- Base Number: 14A163B
- Callout Name: 14A163
$4.22 $3.041 - F81Z-14A163-AAA
Retainer- Christmas tree with 6 inch adjustable plastic tie
- Base Number: 14A163B
- Callout Name: 14A163
$1.73 $1.251
$8.33 $5.851
YC3Z-14A163-CA
Bracket - Wiring Connector- With bracket for 13A576 heavy and light duty TT
- Base Number: 14A163
- Callout Name: 14A163
$41.67 $29.251
$4.00 $2.344
- SHIELD (WIRING)
F5OZ-14A099-EA
Shield Assy- Retains #14401 & #12A581 at firewall
- Base Number: 14A099
- Callout Name: 14A099
$16.67 $12.001
$17.00 $11.931
F81Z-13076-AA
WIRING ASY. (HEADLAMP)Wire Assy- Headlamp to 12A581. Used w/sealed beam headlamps, w/o aero headlamp
- Base Number: 13076
- Callout Name: 13A006
$20.59 $15.071
- F81Z-13076-AA
WIRING ASY. (HEADLAMP LEADS)Wire Assy- Headlamp to 12A581. Used w/sealed beam headlamps, w/o aero headlamp
- Base Number: 13076
- Callout Name: 13076
$20.59 $15.071
YC3Z-13015-AA
RING (HEADLAMP BULB RETAINING)Ring - Headlamp Unit Retaining- LO series,w/single headlamp
- Callout Name: 13015
- Replaced By: 6C2Z-13015-A
$71.68 $44.281
- WIRING ASY. (ALTERNATOR TO VOLTAGE REGULATOR)
2C3Z-14305-BA
Wiring Assy - Alternator- NOTE: For secondary (lower) alternator. Primary (top) alternator harness PIA to engine harness. Diesel w/single alternator, harness PIA to engine harness., 7.3L Diesel, w/dual alternators
- Base Number: 14305
- Callout Name: 14305
-N606688-S301
HARDWAREScrew- Base Number: N611194-S2
- Callout Name: N606688-S301
- Replaced By: -W710603-S439
$4.00 $2.234
$10.00 $5.851
$6.75 $3.954
- $18.75 $13.731
1C3Z-19B555-EA
HOUSING (AIR CONDITIONER EVAPORATOR CORE)Evaporator And Housing Assy- Callout Name: 19B555
- Replaced By: 5C3Z-19B555-BA
$460.00 $281.641
- BRACKET ASY. (BRAKE ANTI-LOCK ACTUATOR)
F81Z-2C325-BA
Bracket- with rear disc brakes , Rear anti lock brake system
- Base Number: 2C325
- Callout Name: 2C325
$20.99 $15.111
- CABLE ASY. (BATTERY - POSITIVE)
2C3Z-14300-CA
Cable Assy - Battery To Battery- diesel, w/o dual alternators, w/automatic transmission
- Fit Note: 8 Cyl 7.3L
- Base Number: 14300
- Callout Name: 14300
$810.00 $491.831 - 2C3Z-14300-CAA
Cable - Battery To Starter Motor- From fuse panel B+ post to J block. (NOTE: cable from J-block to positive battery post is PIA to 14300 battery cable asy. on gas engines. On diesel, it is PIA to 12A581 engine harness).
- Base Number: 14300
- Callout Name: 14300
- 2C3Z-14300-DA
Cable Assy - Battery To Battery- diesel, w/dual alternators, w/automatic transmission
- Fit Note: 8 Cyl 7.3L
- Base Number: 14300
- Callout Name: 14300
- 2C3Z-14300-EA
Cable Assy - Battery To Battery- Positive and Negative cables, Mexico, 5.4L
- Base Number: 14300
- Callout Name: 14300
- 2C3Z-14300-FA
Cable Assy - Battery To Battery- Diesel, w/o dual alternators, w/manual transmission
- Fit Note: 8 Cyl 7.3L
- Base Number: 14300
- Callout Name: 14300
- 2C3Z-14300-GA
Cable Assy - Battery To Battery- Diesel, w/dual alternators, w/manual transmission
- Fit Note: 8 Cyl 7.3L
- Base Number: 14300
- Callout Name: 14300
- CABLE ASY. (BATTERY - NEGATIVE)
2C3Z-14301-AA
Cable Assy- LH standard duty, diesel, w/o dual alternators
- Location: Driver Side
- Fit Note: 8 Cyl 7.3L
- Base Number: 14301
- Callout Name: 14301
$416.52 $302.331
2C3Z-14301-BA
Cable Assy- RH standard duty, diesel, w/o dual alternators
- Location: Passenger Side
- Fit Note: 8 Cyl 7.3L
- Base Number: 14301
- Callout Name: 14301
- 2C3Z-14301-CA
Cable Assy- diesel, w/dual alternators
- Fit Note: 8 Cyl 7.3L
- Base Number: 14301
- Callout Name: 14301
$8.33 $5.851
F65Z-14A163-FB
BRACKET (WIRING CONNECTOR)Bracket - Wiring Connector- Steering column, attachment for #12A644
- Base Number: 14A163K
- Callout Name: 14A206
$21.67 $14.821
- MODULE (INJECTOR DRIVER)
-N807783-S309
Bolt- Special bolt to retain IDM
- Fit Note: 8 Cyl 7.3L
- Require Quantity: 3
- Package Quantity: 1
- Base Number: N807783-S309
- Callout Name: 12B599
- Replaced By: -N807783-S437
XC3Z-12B599-AA
Module - Engine Fuel- Injector Driver Module
- Fit Note: 8 Cyl 7.3L
- Callout Name: 12B599
- Replaced By: HC2Z-12B599-ARM
- WIRE ASY. (ENGINE CONTROL SENSOR)
2C3Z-12A581-GC
Wire Assy- with M/T; without DRL
- Fit Note: 8 Cyl 7.3L
- Base Number: 12A581
- Callout Name: 12A581
- 2C3Z-12A581-HC
Wire Assy- with A/T; without electronic shift,on,the,fly, DRL, fog lamps
- Fit Note: 8 Cyl 7.3L
- Base Number: 12A581
- Callout Name: 12A581
- 2C3Z-12A581-JC
Wire Assy- with A/T, DRL; without electronic shift-on-the-fly
- Fit Note: 8 Cyl 7.3L
- Base Number: 12A581
- Callout Name: 12A581
- 2C3Z-12A581-KC
Wire Assy- with A/T, electronic shift-on-the-fly; without DRL
- Fit Note: 8 Cyl 7.3L
- Base Number: 12A581
- Callout Name: 12A581
- 2C3Z-12A581-MC
Wire Assy- with A/T, DRL, electronic shift-on-the-fly
- Fit Note: 8 Cyl 7.3L
- Base Number: 12A581
- Callout Name: 12A581
- WIRING ASY. (INSTRUMENT PANEL TO DASH PANEL)
2C3Z-14401-AA
Wiring Assy - Main- Gas engines, w/o adjustable pedals, w/o remote keyless entry, 4x2 or 4x4 w/manual transfer case, w/o overhead console, w/o reverse sensning
- Callout Name: 14401
- 2C3Z-14401-DA
Wiring Assy - Main- diesel, w/o adjustable pedals, w/o remote keyless entry, w/o dual fuel tanks
- Base Number: 14401
- Callout Name: 14401
2C3Z-19B573-AA
WIRING ASY. (AIR CONDITIONER CLUTCH COIL LEAD)Wiring Assy- From 12A581 to A/C compressor clutch, A/C pressure/cycling switches., 7.3L, with A/C
- Base Number: 19B573
- Callout Name: 19B573
2C3Z-2B373-CA
VALVE ASY. (BRAKE SKID CONTROL)Control- ECU
- Callout Name: 2B373
- Replaced By: 2C3Z-2C219-CA
- BRACKET (EEC PROCESSOR)
- F81Z-9D816-AA
SWITCH ASY. (SPEED CONTROL DEACTIVATOR)Bracket- bracket and switch located on the brake pedal, w/dealer installed speed control
- Base Number: 9D816
- Callout Name: 9F924
Genuine Ford Parts, the Right Choice
FordPartsGiant.com offers the wholesale prices for genuine 2002 Ford F-550 Super Duty parts. Parts like Wiring System - Engine Compartment are shipped directly from authorized Ford dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 8 Cyl 7.3L Diesel Turbocharged. Transmission: 4AT 4R100.
