Dual Fuel Tanks & Related Parts fit your 2002 Ford F-550 Super Duty 8 Cyl 7.3L Diesel Turbocharged 4-Speed Automatic Transmission 4R100
Currently shopping for
2002 Ford F-550 Super Duty
Change VehicleVehicle Options
8 Cyl 7.3L Diesel Turbocharged; 4-Speed Automatic Transmission 4R100Vehicle Options
8 Cyl 7.3L Diesel Turbocharged; 4-Speed Automatic Transmission 4R100Categories Close X
Currently selected
Fuel System & Manifolds
- Dual Fuel Tanks & Related Parts
- Exhaust Manifold & Related Parts
- Fuel Fill Assembly & Fuel Filler Pipe
- Fuel Filter, Water Separator, Heater & Related Parts
- Fuel Injection Nozzles & Piping & Related Parts
- Fuel Lines, Tank & Related Parts
- Fuel Pump - Frame Mounted - Electric
- Heater Assembly
- Manifold (Turbo Air) & Intake Air Heater
Other Categories
Accelerator Linkage, Air Cleaner & Speed Control
Air Conditioner, Radio & Shock Absorbers
Alternator, Battery, Distributor & Starter
Automatic Transmission
Console, instruments, mirrors, windshield
Door glass and fittings
EM Exterior Moulding
Engine
Fenders & Hood
Frame, Exhaust System & Springs
Front Axle & Steering
Fuel filler, luggage carrier, rear door
IT Body & Soft Trim Parts
Lamps & Wiring
Manual Transmission
Radiator & Grill
Rear Axle, Drive & Coupling Shafts
SM Sheet metal
Seats and belts
Speedometer, Bumpers, Mirrors & Wipers
Wheels & Brakes
How to use OE catalog
Sort by:
Recommended
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
Part Description
FOTZ-9155-B
FILTER ASY. (FUEL - GAS)Filter Assy - Fuel- Uses push connect fittings in conjunction w/frame mounted fuel filter, gas
- Base Number: 9155
- Callout Name: 9155
$36.36 $19.881
- GASKET (FUEL PUMP MOUNTING)
F75Z-9417-BB
Gasket- Used to mount between fuel tank & pump/sender. 146mm ID. Steel tube/flange design on 9H307/9350. Used with 180mm tank opening, Midship fuel tank (Gas)
- Base Number: 9417
- Callout Name: 9417
$17.53 $10.821
F6TZ-9417-AA
Gasket- Gasket-high pressure oil injection pump 9A543, Diesel 7.3L
- Base Number: 9417
- Callout Name: 9417
$66.36 $40.441- F81Z-9417-AA
Gasket- O'ring- Used between 9002 fuel tank & 9275 sender., Midship fuel tank (Diesel)
- Callout Name: 9417
- Replaced By: F75Z-9417-BB
$17.53 $10.821 - F81Z-9417-BA
Gasket- O'ring 131.7mm x 5.3mm. Color=Green. Mounted between 9275 or 9H307 & fuel tank 9002., Aft Axle fuel tank - Diesel
- Callout Name: 9417
- Replaced By: F6DZ-9276-A
$19.00 $12.232
- CAP (FUEL TANK OUTLET TUBE)
F81Z-9G270-BA
Cap- Also serviced in 9155. Cap-Threaded end-fuel filter. Screws into top of 9N180. (#1831193-C91), 7.3L
- Base Number: 9G270
- Callout Name: 9G270
$94.26 $50.501
F81Z-9G270-AA
Cap- Also serviced in 9275. Used on third tube port(aux generator tube) as a end cap, Diesel
- Base Number: 9G270
- Callout Name: 9G270
$133.87 $67.011
$12.00 $7.025
F65Z-9B593-DA
VALVE ASY. (FUEL VAPOR)Valve Assy - Fuel Vapour- 1 port. Mtd to fuel tank. Ref. vent cap 9A089, Chassis Cab
- Fit Note: 8 Cyl 7.3L
- Require Quantity: 2
- Package Quantity: 1
- Base Number: 9B593
- Callout Name: 9B593
$67.67 $46.691
XC3Z-9276-AA
GASKET (FUEL GAUGE TANK UNIT)Gasket- Also serviced in 9275 senders (component of the assembly), Diesel 7.3L & 6.0L; Midship/Aft Axle;Narrow frame WB
- Base Number: 9276
- Callout Name: 9276
$41.00 $25.141
- CROSSMEMBER (FRAME FRONT LOWER)
- 1C3Z-5C128-AA
Crossmember- Front lower blocker beam - less holes for mounting valence, FROM 11/21/00 TO 11/04/02
- Callout Name: 5C128
- Replaced By: 4C3Z-5C128-BA
- YC3Z-6A012-BA
Retainer- Retainer - RH, FROM 11/21/00 TO 11/04/02
- Base Number: 6A012
- Callout Name: 5C128
- YC3Z-6A012-CA
Retainer- Retainer - LH, FROM 11/21/00 TO 11/04/02
- Location: Driver Side
- Base Number: 6A012
- Callout Name: 5C128
$18.50 $10.822
- STRAP ASY. (MID-SHIP FUEL TANK)
F81Z-9054-CA
Strap Assy - Fuel Tank- Rear, Chassis Cab
- Location: Rear
- Base Number: 9092B
- Callout Name: 9054
$70.111
$114.45 $57.991
$201.28 $107.841
F81Z-9054-FA
Strap Assy - Fuel Tank- Front, 165",189",200",201" WB, Midship fuel tank
- Location: Front
- Base Number: 9092A
- Callout Name: 9054
$44.04 $28.131
YC3Z-9054-DA
Strap Assy - Fuel Tank- Front, 137", 158", 172" WB, FROM 7/19/99
- Location: Front
- Callout Name: 9054
$195.53 $101.091
F81Z-9054-EA
Strap Assy - Fuel Tank- Front, 141",162",176" WB, Midship fuel tank
- Location: Front
- Base Number: 9092A
- Callout Name: 9054
$69.74 $38.02
- GAUGE ASY. (SENDER ASY. - FUEL TANK UNIT - DIESEL)
F81Z-9275-DB
Sender Assy - Fuel Tank- Includes gasket XC3U-9276-AB(part of the assembly), Diesel 7.3L - Midship - 141", 162",165",176",189",200",201" WB
- Base Number: 9275
- Callout Name: 9275
$1500.00 $862.131
F81Z-9275-AH
Sender Assy - Fuel Tank- Diesel 7.3L - Midship - 137", 158", 172" WB, FROM 3/26/2001
- Callout Name: 9275
- Replaced By: F81Z-9275-AJ
$860.00 $515.571
XC3Z-9275-AC
Sender Assy - Fuel Tank- Includes gasket XC3U-9276-AB(part of the assembly), aft axle 40 gal. 7.3L
- Base Number: 9275
- Callout Name: 9275
$980.00 $595.061
F81Z-9275-EG
Sender Assy - Fuel Tank- Diesel 7.3L - 142", 156" WB - Midship fuel tank, FROM 3/26/2001
- Base Number: 9275
- Callout Name: 9275
$643.64 $400.02
- GAUGE ASY. (SENDER ASY. - FUEL TANK UNIT - GAS)
F81Z-9A299-FA
Sender Assy- Use with 29 gallon plastic tank; includes (1) F75Z 9417-BB., gas midship tank, 142" & 156" W/B
- Base Number: 9A299
- Callout Name: 9275
$173.40 $107.041
F81Z-9A299-AB
Sender Assy- Use with 38 gallon plastic tank; includes (1) F75Z 9417-BB., gas midship tank; 137", 158" & 172" W/B
- Callout Name: 9275
- Replaced By: F81Z-9A299-AG
$191.60 $115.921
$173.20 $106.921
F81Z-9A299-EB
Sender Assy- Use with 19 gallon steel tank; includes (1) F75Z 9417-BB., Chassis Cab, gas midship tank
- Callout Name: 9275
- Replaced By: 6C3Z-9A299-D
$4.25 $2.494
- CAP ASY. (FUEL TANK FILLER)
YC2Z-9030-AA
Cap Assy - Fuel Tank Filler- Aft Axle and Midship fuel tanks, Diesel-Non-Locking, Screw In Type with Tether, FROM 3/6/2000
Aft Axle and Midship fuel tanks, Gas Leaded Fuel - Non-Locking, Screw In Type with Tether, FROM 3/6/2000 - Callout Name: 9030
- Replaced By: F4TZ-9030-C
$22.62 $13.961
XU5Z-9030-EA
Cap Assy - Fuel Tank Filler- gas, FROM 1/29/2000
- Callout Name: 9030
- Replaced By: XU5Z-9030-MA
$34.73 $21.441
F67Z-9030-DA
Cap Assy - Fuel Tank Filler- locking, screw-on style cap with tether
- Base Number: 9030
- Callout Name: 9030
XU5Z-9030-FA
Cap Assy - Fuel Tank Filler- Accessory, Locking cap, FROM 3/1/2000
- Callout Name: 9030
- Replaced By: YU5Z-9030-AB
F81Z-6A012-AA
NUT AND RETAINER ASY.Nut - Special- Attaches 6a023 support to frame
- Fit Note: 8 Cyl 7.3L
- Callout Name: 6A012
- Replaced By: 6C3Z-6A012-AA
$4.00 $2.344
$16.00 $9.361
F5AZ-9N005-A
SCREW AND SEALER (FUEL TANK COVER)Screw Assy - Sealing- M6 x 1.0 x 12 hex head (screw & washer assy.) , gas
M6 x 1.0 x 12 hex head (screw & washer assy.). Attach 9275 sender to 9002 fuel tank , diesel - Require Quantity: 6
- Package Quantity: 6
- Callout Name: 9N005
- Replaced By: F5AZ-9N005-B
$8.04 $4.426
- BRACKET (FUEL TANK SUPPORT)
F81Z-9046-BA
Bracket- "U" shaped bracket, 8 11/16" between (2) mounting holes, includes M10 nut., 141",162",176"WB, Midship fuel tank
- Callout Name: 9046
- Replaced By: 6C3Z-9046-BA
$50.79 $27.211
$16.00 $9.361
1C3Z-9071-AA
SPACER (FUEL TANK BRACKET TO FRAME)Spacer- Midship fuel tank, 165".201" WB
- Base Number: 9071
- Callout Name: 9071
$8.42 $6.061
- FILTER (GAUGE FUEL TANK UNIT)
E5TZ-9J306-BA
Filter Assy- Intake Fuel Tank Sender, O/8500 GVW; 7.3L
- Base Number: 9A011
- Callout Name: 9A011
$68.00 $47.291 - YC3Z-9A011-AA
Filter Assy- Used to service in,tank fuel pump , aft axle, Mexico
- Base Number: 9A011
- Callout Name: 9A011
E53Z-9H318-A
VALVE ASY. (FUEL SENDER CHECK)Valve Assy - Control- Also serviced in in-tank fuel pump 9H307/9A407. Rubber., except DM & TW Models
Also serviced in in-tank fuel sender 9275 . Rubber., Diesel - Base Number: 9H318
- Callout Name: 9H318
$54.00 $37.58
- TANK ASY. (FUEL)
F81Z-9002-CA
Tank Assy - Fuel- 19 gallon steel midship tank., gas, 141", 162", 165", 176", 189",200",201"WB,
- Callout Name: 9002
F81Z-9002-UA
Tank Assy - Fuel- 19 gallon steel midship tank., Diesel; 141", 162", 165", 176", 189", 200", 201" WB
- Callout Name: 9002
- YC3Z-9002-KB
Tank Assy - Fuel- Plastic midship tank with sonic welded rollover valve, gas, Calif. Ems., 137", 158", 172" W/B, midship, FROM 10/22/99
- Callout Name: 9002
- YC3Z-9002-LB
Tank Assy - Fuel- Plastic midship tank with sonic welded rollover valve, gas, without Calif. Ems., 137", 158", 172" W/B, midship, FROM 10/22/99
- Callout Name: 9002
- YC3Z-9002-MA
Tank Assy - Fuel- Plastic fuel tank. Service rollover valve 9B593 only in 9002 assembly, diesel, 142" & 156" W/B, midship, FROM 10/22/99
- Callout Name: 9002
- YC3Z-9002-NA
Tank Assy - Fuel- Plastic midship tank with sonic welded rollover valve, diesel, 137", 158", 172" W/B, midship
- Callout Name: 9002
- YC3Z-9002-PA
Tank Assy - Fuel- Plastic fuel tank. Service rollover valve 9B593 only in the 9002 assembly, gas, 142" or 156" W/B, with Calif. Ems., midship, FROM 10/22/99
- Callout Name: 9002
- YC3Z-9002-RA
Tank Assy - Fuel- Plastic fuel tank. Service rollover valve 9B593 only in the 9002 assembly , gas, 142" or 156" W/B, without Calif. Ems., midship, FROM 10/22/99
- Callout Name: 9002
Genuine Ford Parts, the Right Choice
FordPartsGiant.com offers the wholesale prices for genuine 2002 Ford F-550 Super Duty parts. Parts like Dual Fuel Tanks & Related Parts are shipped directly from authorized Ford dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 8 Cyl 7.3L Diesel Turbocharged. Transmission: 4AT 4R100.
