Fuel Lines, Tank & Related Parts fit your 2000 Ford Explorer 6 Cyl 4.0L 5-Speed Manual Transmission
Currently shopping for
2000 Ford Explorer
Change VehicleVehicle Options
6 Cyl 4.0L; 5-Speed Manual TransmissionVehicle Options
6 Cyl 4.0L; 5-Speed Manual TransmissionCategories Close X
Currently selected
Fuel System & Manifolds
- Emission System - Exhaust Gas - Recirculation (E.G.R.)
- Evap Tube & Related Parts
- Exhaust Gas Oxygen (Hego) & Catalyst Temp. Monitor (Ctm) Sensors
- Exhaust Manifold
- Fuel Filler Pipe Installation
- Fuel Injection Manifold Injectors, Valves & Wiring
- Fuel Injection Manifold, Injectors, Valves & Wiring Supply & Return Fuel Sytem
- Fuel Injection Pulse Dampener, Tubing & Wiring - Returnless Fuel System
- Fuel Lines, Tank & Related Parts
- Fuel Rail Tube Assembly - Supply Returnless Fuel System
- Intake Manifold Tube Assembly - Brake
- Manifold & Related Parts - Exhaust
- Vacuum System - Front Axle
- Vapor Management Valve & Lines
Other Categories
Accelerator Linkage, Air Cleaner & Speed Control
Air Conditioner, Radio & Shock Absorbers
Alternator, Battery, Distributor & Starter
Console, instruments, mirrors, windshield
Door glass and fittings
EM Exterior Moulding
Engine
Fenders & Hood
Frame, Exhaust System & Springs
Front Axle & Steering
Fuel filler, luggage carrier, rear door
IT Body & Soft Trim Parts
Lamps & Wiring
Manual Transmission
Radiator & Grill
Rear Axle, Drive & Coupling Shafts
SM Sheet metal
Seats and belts
Speedometer, Bumpers, Mirrors & Wipers
Wheels & Brakes
Parts Questions
Sort by:
Recommended
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
Part Description
- FILTER ASY. (FUEL - GAS)
F89Z-9155-A
Filter Assy - Fuel- Use push connector fittings, detail of 9L291 (service details only) tube asy. -fuel/brake bundle
- Base Number: 9155
- Callout Name: 9155
- Replaced By: 2M5Z-9155-CA
$31.82 $20.391
$72.36 $46.091
XL5Z-9155-AA
Filter Assy - Fuel- English/ French label, Flex Fuel - Postal
- Base Number: 9155
- Callout Name: 9155
$40.00 $25.301
- CLIP (FUEL TUBE)
FOAZ-9A317-B
Clip- 9.5mm & 7.9mm clip & clamp with tether (attach supply fuel line to fuel filter & to fuel pump)
- Require Quantity: 2
- Package Quantity: 2
- Base Number: 9C040
- Callout Name: 9A317
$8.50 $4.972
$40.00 $23.001
F3DZ-9A317-BFFV
Clip- 7.9 & 13.8mm reduntant clip. Secures 9S326 Sensor/bracket to fuel line, Flex Fuel Ethanol
- Require Quantity: 2
- Package Quantity: 1
- Base Number: N806238-S
- Callout Name: 9A317
- Replaced By: -N807397-S441
$36.46 $26.681
$6.26 $4.02
FO3Z-9A317-AA
Clip- Mounted to coil bracket to retain speed control/accelerator cables, 5.0L
- Callout Name: 9A317
- FOAZ-9A317-B
CLIP ASY. (FUEL LINE VAPOR TO FRAME)Clip- 9.5mm & 7.9mm clip & clamp w/tether (attach supply fuel line to fuel filter & to fuel pump)
- Require Quantity: 2
- Package Quantity: 2
- Base Number: 9C040
- Callout Name: 9F274
$8.50 $4.972
F67Z-9B593-CA
VALVE ASY. (FUEL VAPOR)Valve Assy - Fuel Vapour- In-tank mounted
- Fit Note: 6 Cyl 4.0L, 8 Cyl 5.0L
- Base Number: 9B593
- Callout Name: 9B593
$35.27 $22.701
- CAP ASY. (FUEL TANK FILLER)
F7DZ-9030-AA
Cap Assy - Fuel Tank Filler- non-locking cap; 1/8th turn type, BEFORE 1/13/2000
- Callout Name: 9030
- Replaced By: XU5Z-9030-JA
$29.49 $18.491
YL2Z-9030-AA
Cap Assy - Fuel Tank Filler- Mexico; locking cap; 1/8th turn type
- Base Number: 9030
- Callout Name: 9030
$10.00 $5.854
$5.65 $3.314
- TUBE (FUEL TANK VENT TO STORAGE CANISTER)
F57Z-9A228-BC
Tube - Fuel Vapour- Outlet tube - Fuel/Vapor Storage Cannister; from cannister to engine., 4 door
- Base Number: 9A228
- Callout Name: 9A228
$140.18 $87.891
F57Z-9A228-C
Tube - Fuel Vapour- Inlet tube - Fuel/Vapor Storage Cannister; from tank to cannister.
- Base Number: 9A228
- Callout Name: 9A228
$98.00 $61.451- F57Z-9A228-AC
Tube - Fuel Vapour- Outlet tube - Fuel/Vapor Storage Cannister; from cannister to engine., 2 door
- Base Number: 9A228
- Callout Name: 9A228
-N620482-S427
HARDWARENut - Adjusting Screw- Base Number: HN1
- Callout Name: N620482-S427
- Replaced By: -N620482-S439
$28.75 $16.824
- TUBE ASY. (FUEL FILTER SUPPLY)
$191.67 $135.961
XL2Z-9A274-BA
Tube Assy- Filter to sensor, Flex Fuel Vehicle only (Postal Vehicle)
- Base Number: 9A274
- Callout Name: 9A274
$211.67 $117.151- $305.00 $199.471
F7UZ-9077-AA
PLUG (FUEL TANK DRAIN BALL CHECK)Plug- Plug for pressure transducer "9C052"
- Base Number: 9077
- Callout Name: 9077
$19.70 $10.831
- PLATE (FUEL TANK SKID)
- TUBE ASY. (FUEL SUPPLY)
XL2Z-9J280-AA
Pipe - Fuel- QSF-64-0215. Convert to cleanside fuel system, 2 door
- Base Number: 9J280
- Callout Name: 9J280
$898.33 $603.681
F77Z-9J280-PA
Pipe - Fuel- Supply from tank to filter., (4 door)
- Base Number: 9J280
- Callout Name: 9J280
$188.33 $128.82
- TANK ASY. (FUEL)
F87Z-9002-SA
Tank Assy - Fuel- For systems without fuel tank pressure sensor 9C052. Use only with F87Z,9034,BB , 112" W/B, without on,board diagnostic system
- Callout Name: 9002
- F87Z-9002-NA
Tank Assy - Fuel- For systens with fuel tank pressure sensor 9C052. Use only with F87Z,9034,BB, 112" W/B, with on,board diagnostic system
- Callout Name: 9002
- F87Z-9002-MA
Tank Assy - Fuel- With pressure transducer hole , 2 door, 102" W/B
- Base Number: 9002
- Callout Name: 9002
F57Z-9276-AC
GASKET (FUEL GAUGE TANK UNIT)Gasket- 1/2" wide gasket with 4 mounting tabs
- Base Number: 9276
- Callout Name: 9276
$23.75 $14.891
$13.00 $7.611
- TUBE (VAPOR)
$64.91 $41.411
F5AZ-9N005-A
SCREW AND SEALER (FUEL TANK COVER)Screw Assy - Sealing- M6 x 1.0 x 12 hex head (screw & washer assy.)
- Require Quantity: 6
- Package Quantity: 6
- Callout Name: 9N005
- Replaced By: F5AZ-9N005-B
$7.31 $4.016
$2.50 $1.761
$10.00 $5.854
$3.25 $1.914
$4.25 $2.494
$0.98 $0.691
- BRACKET (FUEL TANK SUPPORT)
F67Z-9046-AA
Bracket- Front bracket, includes weld nuts & rubber washers., FROM 1/25/2000
- Base Number: 9046
- Callout Name: 9046
$3151.06 $68.271 - $3151.06 $1658.721
F77Z-9E313-BA
GUARD (FUEL HOSE)Shield - Fuel Tubes- OHV/SOHC
- Fit Note: 6 Cyl 4.0L
- Base Number: 9E313
- Callout Name: 9E313
$32.77 $17.561
- PIPE ASY. (FUEL TANK FILLER)
F87Z-9034-BB
Pipe - Fuel Filler- Unleaded, BEFORE 1/19/2000
- Callout Name: 9034
- Replaced By: XL2Z-9034-CA
$821.67 $650.761 - $821.67 $650.761
- XL2Z-9034-FA
Pipe - Fuel Filler- Flex Fuel Ethanol - Postal Vehicle
- Callout Name: 9034
- Replaced By: XL2Z-9034-FB
$541.67 $343.851 - $541.67 $343.851
XL2Z-9054-HA
STRAP ASY. (MID-SHIP FUEL TANK)Strap Assy - Fuel Tank- Rear strap
- Base Number: 9092
- Callout Name: 9054
$63.19 $34.451
XL2Z-9180-AA
BRACKET (FUEL FILTER MOUNTING)Bracket- Includes XL2Z 9F276,AA fuel line retaining clip.
- Base Number: 9180
- Callout Name: 9180
$96.00 $70.261
- CLIP (FUEL AND BRAKE LINEXL2Z-9F276-AA
Clip - Brake Pipe- 5 tube holder (1 fuel vapor, 1 brake, 1 fuel line); also serviced in XL2Z-9180-AA bracket. Located at just before filter and forward on fuel line bundle.
- Require Quantity: 6
- Package Quantity: 1
- Base Number: 9F276
- Callout Name: 9F276
$71.50 $49.761 - XL2Z-9F276-BA
Clip - Brake Pipe- 3 tube holder (2 fuel vapor & 1 brake line). Located between fuel tank to canister.
- Require Quantity: 3
- Package Quantity: 1
- Base Number: 9F276
- Callout Name: 9F276
$71.50 $49.761 - XL2Z-9F276-CA
Clip - Brake Pipe- 3 tube holder (1 fuel vapor, 1 brake line & 1 fuel supply). Located between fuel tank & filter.
- Callout Name: 9F276
- Replaced By: XL2Z-9F276-AA
$71.50 $49.761 - XL2Z-9F276-DA
Clip - Brake Pipe- 3 tube holder (2 fuel vapor & 1 brake line). Located near canister.
- Callout Name: 9F276
- Replaced By: XL2Z-9F276-BA
$71.50 $49.761
YL2Z-9L291-DA
TUBE ASY. (FUEL AND BRAKE)Tube Assy- Flex Fuel Ethanol
- Base Number: 9L291
- Callout Name: 9L291
$851.67 $572.321
- PUMP ASY. (FUEL PUMP AND SENDER ASY. - TANK UNIT - GAS)
1L2Z-9H307-A
Sender And Pump Assy- Stripped Chassis - Unleaded fuel
- Base Number: 9H307
- Callout Name: 9350
- Replaced By: 1L2Z-9H307-B
1L2Z-9H307-GA
Sender And Pump Assy- Has gas fuel pump, Stripped Chassis Flex Fuel Ethanol
- Callout Name: 9350
F57Z-9H307-D
Sender And Pump Assy- Gasket F57U-9276-AC included in 9H307, 2-Door - Mexico
- Callout Name: 9350
- GAUGE ASY. (SENDER ASY. - FUEL TANK UNIT - GAS)
- TUBE (FUEL VAPOR CANISTER PURGE OUTLET)
- FUEL LINE ASY. (FUEL SUPPLY)
XL2Z-9E964-AA
Pipe - Fuel- Supply line to fuel rail. Mounting screw W500212-S3091 M6 x 14, SOHC, BEFORE 1/1/00
- Fit Note: 6 Cyl 4.0L
- Base Number: 9E964
- Callout Name: 9E964
- XL2Z-9E964-AD
Pipe - Fuel- Supply line to fuel rail. Mounting screw W500203-S309 M5, SOHC, FROM 1/1/00
- Fit Note: 6 Cyl 4.0L
- Base Number: 9E964
- Callout Name: 9E964
- XL2Z-9E964-BA
Pipe - Fuel- Supply line to fuel rail. Mounting screw W500212-S3091 M6, (RHD Postal) SOHC, BEFORE 1/1/00
- Fit Note: 6 Cyl 4.0L
- Base Number: 9E964
- Callout Name: 9E964
- XL2Z-9E964-BC
Pipe - Fuel- Supply line to fuel rail. Mounting screw W500203,S309 M5., (RHD Postal) SOHC, FROM 1/1/00
- Fit Note: 6 Cyl 4.0L
- Base Number: 9E964
- Callout Name: 9E964
$611.67 $414.71
Genuine Ford Parts, the Right Choice
FordPartsGiant.com offers the wholesale prices for genuine 2000 Ford Explorer parts. Parts like Fuel Lines, Tank & Related Parts are shipped directly from authorized Ford dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 6 Cyl 4.0L. Transmission: 5MT.
