Genuine Ford Ranger Car Mirror

Interior Rear View Mirror

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

101 Car Mirrors found

View related parts
Ford Ranger Mirror - Interior Rear View - Di
Part Number: 5M5Z-17000-A
$49.04 MSRP: $63.82
You Save: $14.78 (24%)
ADD TO CART
Product Specifications
- Other Name: Mirror - Interior Rr View - Dipping; Mirror Inside
- Manufacturer Note: For Vehicles Fitted With Rain Sensor
- Position: Rear
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2019-2025 Ford Ranger | 4 Cyl 2.3 L GAS, 4 Cyl 2.3L TIVCT DI TC, 6 Cyl 2.7 L GAS | 10-Speed Automatic Transmission (10R80), 2 Whl L/H Rear Drive-High Ride, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive
View related parts
Ford Ranger Rear View Mirror Assembly Inner
Part Number: CU5Z-17700-B
$175.16 MSRP: $256.08
You Save: $80.92 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Mirror Assembly - Rear View - Inner; Mirror Inside
- Position: Rear Inner
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2019-2023 Ford Ranger | 4 Cyl 2.3 L GAS, 4 Cyl 2.3L TIVCT DI TC | 10-Speed Automatic Transmission (10R80), 2 Whl L/H Rear Drive-High Ride, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive
View related parts
Ford Ranger Rear View Mirror Assembly Inner
Part Number: DU5Z-17700-U
$639.79 MSRP: $978.27
You Save: $338.48 (35%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Mirror Assy - Rear View - Inner; Mirror Inside
- Position: Rear Inner
- Replaces: BU5Z-17700-K, BU5Z-17700-Q
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2019-2023 Ford Ranger | 4 Cyl 2.3 L GAS, 4 Cyl 2.3L TIVCT DI TC | 10-Speed Automatic Transmission (10R80), 2 Whl L/H Rear Drive-High Ride, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive
View related parts
Ford Ranger Rear View Outer Mirror Glass Assembly
Part Number: F57Z-17K707-K
$46.68 MSRP: $63.78
You Save: $17.10 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Glass Assembly - Rear View Outer Mirror; Mirror Glass
- Manufacturer Note: RH - mirror head, Type 17 - manual
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1995-2005 Ford Ranger | 4 Cyl 2.3L, 4 Cyl 2.3L NA Petrol, 4 Cyl 2.5L, 6 Cyl 3.0L, 6 Cyl 3.0L OHV EFI, 6 Cyl 4.0L, 6 Cyl 4.0L SOHC EFI | 4AT 4R44E, 4AT 4R55E, 4AT A4LD, 5AT 5R44E, 5AT 5R55E, 5MT, 5-Speed Automatic Transmission - 5R44E/5R55E, 5-Speed Manual Transmission - R1HD, 5-Speed Manual Transmission M5R1, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Ranger Mirror Assembly Rear View Outer
Part Number: 8L5Z-17682-AA
$55.69 MSRP: $81.42
You Save: $25.73 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Mirror Assy - Rear View Outer; Mirror Assembly
- Manufacturer Note: Solid Housing. 17D742 Cover Not Required
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2008-2011 Ford Ranger | 4 Cyl 2.3L NA Petrol, 6 Cyl 3.0L OHV EFI, 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission - 5R44E/5R55E, 5-Speed Manual Transmission - R1HD, 5-Speed Manual Transmission M5R1, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Ranger Rear View Outer Mirror Assembly
Part Number: E5TZ-17682-D
$120.15 MSRP: $164.17
You Save: $44.02 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Mirror Assy - Rear View Outer; Mirror
- Position: Driver Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1985-1992 Ford Ranger | 4 Cyl 2.0L, 4 Cyl 2.3L, 6 Cyl 2.8L, 6 Cyl 2.9L, 6 Cyl 3.0L, 6 Cyl 4.0L | 4AT A4LD, 5MT
View related parts
Ford Ranger Rear View Outer Mirror Glass Assembly
Part Number: F57Z-17K707-J
$38.24 MSRP: $55.90
You Save: $17.66 (32%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Glass Assy - Rear View Outer Mirror; Mirror Glass
- Manufacturer Note: LH - mirror head, Type 17 - manual
- Position: Driver Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1995-2005 Ford Ranger | 4 Cyl 2.3L, 4 Cyl 2.3L NA Petrol, 4 Cyl 2.5L, 6 Cyl 3.0L, 6 Cyl 3.0L OHV EFI, 6 Cyl 4.0L, 6 Cyl 4.0L SOHC EFI | 4AT 4R44E, 4AT 4R55E, 4AT A4LD, 5AT 5R44E, 5AT 5R55E, 5MT, 5-Speed Automatic Transmission - 5R44E/5R55E, 5-Speed Manual Transmission - R1HD, 5-Speed Manual Transmission M5R1, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Ranger Mirror Assembly Rear View Outer
Part Number: KB3Z-17682-F
$357.68 MSRP: $559.75
You Save: $202.07 (37%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: MIRROR ASY - REAR VIEW OUTER; Mirror, Mirror Assembly
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2019-2023 Ford Ranger | 4 Cyl 2.3 L GAS, 4 Cyl 2.3L TIVCT DI TC | 10-Speed Automatic Transmission (10R80), 2 Whl L/H Rear Drive-High Ride, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive
View related parts
Ford Ranger Mirror Assembly Rear View Outer
Part Number: KB3Z-17683-B
$166.78 MSRP: $258.57
You Save: $91.79 (36%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: MIRROR Assembly - REAR VIEW OUTER; Mirror, Mirror Assembly
- Position: Driver Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2019-2023 Ford Ranger | 4 Cyl 2.3 L GAS, 4 Cyl 2.3L TIVCT DI TC | 10-Speed Automatic Transmission (10R80), 2 Whl L/H Rear Drive-High Ride, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive
View related parts
Ford Ranger Mirror Assembly Rear View Outer
Part Number: KB3Z-17682-A
$110.72 MSRP: $171.18
You Save: $60.46 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: MIRROR ASY - REAR VIEW OUTER; Mirror, Mirror Assembly
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2019-2023 Ford Ranger | 4 Cyl 2.3 L GAS, 4 Cyl 2.3L TIVCT DI TC | 10-Speed Automatic Transmission (10R80), 2 Whl L/H Rear Drive-High Ride, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive
View related parts
Ford Ranger Mirror Assembly Rear View Outer
Part Number: 6L5Z-17683-AA
$97.40 MSRP: $133.09
You Save: $35.69 (27%)
ADD TO CART
Product Specifications
- Other Name: Mirror Assy - Rear View Outer; Mirror Assembly
- Manufacturer Note: Solid Housing. 17D742 Cover Not Required
- Position: Driver Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2006-2007 Ford Ranger | 4 Cyl 2.3L NA Petrol, 6 Cyl 3.0L OHV EFI, 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission - 5R44E/5R55E, 5-Speed Manual Transmission - R1HD, 5-Speed Manual Transmission M5R1, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Ranger MIRROR ASY - LESS AR
Part Number: E5TZ17723B
$69.44 MSRP: $94.89
You Save: $25.45 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Mirror Assembly
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1990 Ford Ranger | 4 Cyl 2.3L, 6 Cyl 2.9L, 6 Cyl 4.0L | 4AT A4LD, 5MT
- 1984-1988 Ford Ranger | 4 Cyl 2.0L, 4 Cyl 2.2L, 4 Cyl 2.3L, 6 Cyl 2.8L, 6 Cyl 2.9L | 3AT C3, 3AT C5, 4AT A4LD, 4MT, 5MT
View related parts
Ford Ranger Rear View Outer Mirror Assembly
Part Number: F87Z-17682-SAACP
$59.29 MSRP: $81.02
You Save: $21.73 (27%)
ADD TO CART
Product Specifications
- Other Name: Mirror Assy
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1998-2005 Ford Ranger | 4 Cyl 2.3L, 4 Cyl 2.3L NA Petrol, 4 Cyl 2.5L, 6 Cyl 3.0L, 6 Cyl 3.0L OHV EFI, 6 Cyl 4.0L, 6 Cyl 4.0L SOHC EFI | 4AT 4R44E, 5AT 5R44E, 5AT 5R55E, 5MT, 5-Speed Automatic Transmission - 5R44E/5R55E, 5-Speed Manual Transmission - R1HD, 5-Speed Manual Transmission M5R1, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Ranger Rear View Outer Mirror Assembly
Part Number: F57Z-17682-BCP
$89.43 MSRP: $122.19
You Save: $32.76 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Mirror Assy
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1995-2005 Ford Ranger | 4 Cyl 2.3L, 4 Cyl 2.3L NA Petrol, 4 Cyl 2.5L, 6 Cyl 3.0L, 6 Cyl 3.0L OHV EFI, 6 Cyl 4.0L, 6 Cyl 4.0L SOHC EFI | 4AT 4R44E, 4AT 4R55E, 4AT A4LD, 5AT 5R44E, 5AT 5R55E, 5MT, 5-Speed Automatic Transmission - 5R44E/5R55E, 5-Speed Manual Transmission - R1HD, 5-Speed Manual Transmission M5R1, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Ranger Mirror Glass Wide Angle
Part Number: F37Z17K707E
$28.60 MSRP: $39.07
You Save: $10.47 (27%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Mirror Glass - Wide Angle - Adhesve
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1993-1994 Ford Ranger | 4 Cyl 2.3L, 6 Cyl 3.0L, 6 Cyl 4.0L | 4AT A4LD, 5MT
View related parts
Ford Ranger Mirror Assembly Rear View Outer
Part Number: 8L5Z-17682-EA
$75.37 MSRP: $110.18
You Save: $34.81 (32%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Mirror Assembly - Rear View Outer; Mirror Assembly
- Manufacturer Note: Excludes Cover, See Basic 17D742
- Position: Passenger Side
- Replaces: 6L5Z-17682-EA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2006-2011 Ford Ranger | 4 Cyl 2.3L NA Petrol, 6 Cyl 3.0L OHV EFI, 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission - 5R44E/5R55E, 5-Speed Manual Transmission - R1HD, 5-Speed Manual Transmission M5R1, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Ranger Rear View Outer Mirror Glass Assembly
Part Number: KB3Z-17K707-B
$164.85 MSRP: $249.77
You Save: $84.92 (34%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: GLASS ASY - REAR VIEW OUTER MI; Mirror Glass
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2019-2023 Ford Ranger | 4 Cyl 2.3 L GAS, 4 Cyl 2.3L TIVCT DI TC | 10-Speed Automatic Transmission (10R80), 2 Whl L/H Rear Drive-High Ride, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive
View related parts
Ford Ranger Mirror Assembly Rear View Outer
Part Number: 4L5Z-17682-BAA
Product Specifications
- Other Name: Mirror Assembly - Rear View Outer; Mirror Assembly
- Position: Passenger Side
- Replaces: F87Z-17682-RAA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1999-2005 Ford Ranger | 4 Cyl 2.3L, 4 Cyl 2.3L NA Petrol, 4 Cyl 2.5L, 6 Cyl 3.0L, 6 Cyl 3.0L OHV EFI, 6 Cyl 4.0L, 6 Cyl 4.0L SOHC EFI | 4AT 4R44E, 5-Speed Automatic Transmission - 5R44E/5R55E, 5-Speed Manual Transmission - R1HD, 5-Speed Manual Transmission M5R1, 5AT 5R44E, 5AT 5R55E, 5MT, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Ranger Mirror Assembly Rear View Outer
Part Number: KB3Z-17682-FAPTM
Product Specifications
- Other Name: MIRROR ASY - REAR VIEW OUTER; Mirror, Mirror Assembly
- Manufacturer Note: Paint to match
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2019-2023 Ford Ranger | 4 Cyl 2.3 L GAS, 4 Cyl 2.3L TIVCT DI TC | 10-Speed Automatic Transmission (10R80), 2 Whl L/H Rear Drive-High Ride, Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive
View related parts
Ford Ranger Mirror Assembly Rear View Outer
Part Number: F87Z-17682-RAA
Product Specifications
- Other Name: Mirror Assy - Rear View Outer
- Manufacturer Note: Type 18 - RH - Black - convex, manual (styled)
- Position: Passenger Side
- Replaced by: 4L5Z-17682-BAA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1999-2003 Ford Ranger | 4 Cyl 2.3L, 4 Cyl 2.5L, 6 Cyl 3.0L, 6 Cyl 4.0L | 4AT 4R44E, 5AT 5R44E, 5AT 5R55E, 5MT

| Page 1 of 6 |Next >

1-20 of 101 Results

Ford Ranger Car Mirror

The Ford Ranger Car Mirror provides drivers with an informative view of the surroundings behind and to the sides of the truck, allowing clearer and farther visibility just like a regular Car Mirror. This makes it easier to change lanes and maneuver through tight spots. Each Car Mirror is positioned on the door near the A pillar. It may be set by hand or moved remotely. With current Ford pickups offering memory, heating, auto dimming, and power folding, the glass is protected. Earlier models of the Ranger with flat glass provided a true reflection. In later years, the convex Car Mirror or aspheric option offered a wider view but made objects appear farther away. The regulations still require that the driver's side remains undistorted, so the truck has a planar left Car Mirror and a curved right one to balance vision. Beginning in the late 1960s, every Ford midsize pickup passed the passenger side as standard equipment. The folding joint would arrive sometime in the 2000s, limiting damage in tight parking spots. The recent Ranger editions are testing digital camera alternatives that stream live pictures to cabin screens, and while they reduce wind drag, they also aim to create a conventional Car Mirror for drivers. Irrespective of being flat, convex, aspheric, and video-enabled, the Ford design focus is on clear sight lines so every Ranger driver can safely navigate through traffic.

We provide a wide range of Ford Ranger Car Mirror at the optimal prices. If you need Ford Ranger Car Mirror, you can shop with confidence on our website. All our OEM parts come with a manufacturer's warranty and are delivered to your doorstep with a fast delivery service.

Ford Ranger Car Mirror Parts Questions & Experts Answers

Rear View Mirror Assembly Inner
6U5Z-17700-D
Q: How do electric rear view car mirrors operate and what steps should be taken if they malfunction on Ford Ranger?
A:
The electric rear view mirrors utilize two motors for adjustments, one for vertical movement and another for horizontal movement. The control switch features a selector that directs voltage to either the left or right mirror. With the ignition in the ACC position, roll down the windows and operate the mirror control switch through all functions for both mirrors, listening for the sound of the motors. If no sound is heard or the mirror glass remains stationary, there may be an issue with the drive mechanism, necessitating removal and disassembly of the mirror to identify the problem. If the mirrors are unresponsive and silent, check the mirror fuse in the fuse block. If the fuse is intact, access the back of the mirror control switch by removing the switch bezel without disconnecting the attached wire, then turn the ignition On to check for voltage at the switch; there should be voltage at one terminal. In the absence of voltage, inspect the wiring between the fuse panel and switch for any faults. If voltage is present, disconnect the switch and test for continuity in all operating positions; replace the switch if continuity is lacking. Reconnect the switch and locate the wire leading to ground; while keeping the switch connected, use a jumper wire to connect this wire to ground. If the mirror operates normally, repair the faulty ground connection. If the mirror remains nonfunctional, remove it and check the wires for voltage while the ignition is On and the selector switch is set appropriately, ensuring voltage is present at one of the switch-to-mirror wires in each position except the neutral "off" position. If voltage is absent in any position, inspect the wiring between the mirror and switch for issues. If voltage is confirmed, test the mirror off the vehicle using jumper wires and replace it if it fails this test.
