Genuine Ford Edge Differential

Ford Edge Differential Parts Questions & Answers

• Gear Assembly - Planet
  9L8Z-7F465-H
  Q: How to remove and install Differential on Ford Edge AWD model?

  A: On AWD models, the manufacturer uses an Active Torque Control Coupling (ATCC) to manage power distribution to the front and rear wheels. Normally, the front wheels receive the majority of the torque produced by the engine. When the ATCC system senses wheel slip, it automatically increases the torque to the rear wheels. The system is always active, continuously monitoring vehicle conditions and adjusting the torque being delivered to the rear wheels by controlling the current sent to an electric clutch device inside the rear axle. The ATCC system has no mode selector nor does it require any driver input. The ATCC solenoid in the rear axle is not repairable and must be replaced with the rear axle assembly as a unit. To do this, raise the rear of the vehicle and support it securely on jackstands. Block the front wheels to prevent the vehicle from rolling. Remove the driveshaft, driveaxles, and the rear stabilizer bar. Support the rear axle housing with a floor jack. Disconnect the electrical connector on the cross member. There are four rear differential mounting brackets securing the differential to the sub-frame, one at either side at the top-front of the assembly and two at the top-rear. Remove the four bolts (two each side) securing the differential to each front bracket. Loosen the two front mounting brackets from the sub-frame and swing the brackets out to allow clearance to lower the rear differential. Remove the five bolts securing the differential to the rear mounting brackets. Lower the differential with the floor Jack. Installation is the reverse of removal. Tighten all fasteners to the torque.
